Operating the monitor 33
Operating the monitor
Power on the monitor
Press the button to turn on the monitor.
Figure 25. Power on the monitor
Using the front panel controls
Use the control buttons at the bottom edge of the monitor to adjust the image being displayed.
1
2
3
4 5
Figure 26. Front panel controls
The following table describes the control buttons:
Table 17. Control buttons description.
Control buttons Description
1
Preset mode
Use this button to choose from a list of preset modes.
2
Volume
Use the Volume key to direct access to the "Volume" control menu.
3
Menu
To launch the On-Screen Display (OSD) menu, or to access the list of items/options
of a menu item. For more information, see Accessing the OSD menu.
4
Exit
To exit or return to the OSD main menu.
5
Power button
(with power-status light)
To turn the monitor on or off.
Solid white light indicates that the monitor is turned on and functioning normally.
Blinking white light indicates that the monitor is in Standby Mode.
