16 About your monitor
Electrical specifications
Table 11. Electrical specifications.
Model E2225HSM E2425HSM
Video input signals • Analog RGB: 0.7 V ± 5 %, 75 Ω input impedance
• DP 1.2, 600 mV for each differential line, 100 Ω input impedance per differential pair
• HDMI 1.4, 600 mV for each differential line, 100 Ω input impedance per differential pair
Synchronization input
signals
Separate horizontal and vertical synchronizations, polarity-free TTL level,
SOG (Composite SYNC on green)
Input voltage/frequency/
current
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz /
0.7 A (typical)
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 0.7
A (typical)
Inrush current • 120 V: 30 A (maximum) at 0°C (cold start)
• 240 V: 60 A (maximum) at 0°C (cold start)
Power Consumption • 0.3 W (Off Mode)
1
• 0.3 W (Standby Mode)
1
• 11.4 W (On Mode)
1
• 25 W (Max)
2
• 11.54 W (P
on
)
3
• 37.0 kWh (TEC)
3
• 0.3 W (Off Mode)
1
• 0.3 W (Standby Mode)
1
• 12.1 W (On Mode)
1
• 28.5 W (Max)
2
• 11.94 W (P
on
)
3
• 38.32 kWh (TEC)
3
1
As defined in EU 2019/2021 and EU 2019/2013.
2
Max brightness and contrast setting.
3
P
on
: Power consumption of On Mode as defined in Energy Star 8.0 version.
TEC: Total energy consumption in kWh as defined in Energy Star 8.0 version.
This document is informational only and reflects laboratory performance. Your product may perform differently, depending on the
software, components, and peripherals you ordered, and you shall have no obligation to update such information.
So, the customer should not rely upon this information in deciding about electrical tolerances or otherwise. No warranty as to
accuracy or completeness is expressed or implied.
NOTE: This monitor is ENERGY STAR certified.
This product qualifies for ENERGY STAR in the factory default settings which can be restored by Factory Reset
function in the OSD menu. Changing the factory default settings or enabling other features may increase power
consumption that could exceed the ENERGY STAR specified limit.
