About your monitor 13
Monitor specifications
Table 7. Monitor specifications.
Model E2225HSM E2425HSM
Screen type Active matrix-TFT LCD Active matrix-TFT LCD
Panel technology Vertical Alignment (VA) Technology In-Plane Switching (IPS) Technology
Aspect ratio 16:9 16:9
Viewable image dimensions
Diagonal 544.8 mm (21.5 in.) 604.7 mm (23.8 in.)
Active area
Horizontal 478.66 mm ( 18.84 in.) 527.04 mm (20.75 in.)
Vertical 260.28 mm ( 10.25 in.) 296.46 mm (11.67 in.)
Area 124584.58 mm
2
(193.11 in.
2
) 156246.28 mm
2
(242.18 in.
2
)
Pixel pitch
Horizontal 0.2493 mm 0.2745 mm
Vertical 0.2410 mm 0.2745 mm
Pixel per inch (PPI) 103 93
Viewing angle
Horizontal 178° (typical) 178° (typical)
Vertical 178° (typical) 178° (typical)
Brightness 250 cd/m² (typical) 250 cd/m² (typical)
Contrast ratio 3000 : 1 (typical) 1000 : 1 (typical)
Faceplate coating Anti-glare with hard-coating 3H Anti-glare with hard-coating 3H
Backlight LED Edgelight System LED Edgelight System
Response time (Gray to Gray) Normal mode: 8.0 ms (gray to gray)
Fast mode: 5.0 ms (gray to gray)
Normal mode: 8.0 ms (gray to gray)
Fast mode: 5.0 ms (gray to gray)
Color depth 16.7 million colors 16.7 million colors
Color gamut NTSC 72% (CIE 1931) (minimum) NTSC 72% (CIE 1931) (minimum)
Dell Display and Peripheral Manager Yes Yes
Connectivity • 1 x HDMI port (HDCP 1.4) (supports
up to FHD 1920 x 1080, 100 Hz as per
specified in HDMI 1.4)
• 1 x DisplayPort 1.2 (HDCP 1.4) port
(Supports up to FHD 1920 x 1080, 100
Hz)
• 1 x VGA port
• 1 x HDMI port (HDCP 1.4) (supports
up to FHD 1920 x 1080, 100 Hz as per
specified in HDMI 1.4)
• 1 x DisplayPort 1.2 (HDCP 1.4) port
(Supports up to FHD 1920 x 1080, 100
Hz)
• 1 x VGA port
Bezel width (edge of the monitor to
active area)
6.70 mm (0.26 in.) (Top)
6.70 mm (0.26 in.) (Left/Right)
17.15 mm (0.68 in.) (Bottom)
5.80 mm (0.23 in.) (Top)
5.80 mm (0.23 in.) (Left/Right)
17.43 mm (0.69 in.) (Bottom)
Security Security-lock slot (cable lock sold
separately)
Security-lock slot (cable lock sold
separately)
Tilt angle -5° to 21° -5° to 21°
Height adjustable stand 130 ± 5 mm 130 ± 5 mm
Swivel (Lazy Susan) -173° to 173° -173° to 173°
Pivot -90° to 90° -90° to 90°
Built-in Speakers
(2 x 2 W sound output)
Speaker 2 x 2 W Speaker 2 x 2 W
