Operating the monitor 39
Table 21. OSD tree list.
Icon Menu and submenus Description
Brightness/Contrast Use this option to control the brightness or contrast settings.
Dell Pro 2X Adjustable Stand Monitor - E2X25HSM
Brightness / Contrast
Auto Adjust
Input Source
75%
75%
Color
Display
Menu
Audio
Personalize
Others
More Information
Brightness Brightness adjusts the luminance of the backlight (minimum 0; maximum 100).
Press the
button to increase the brightness and press the button to decrease the
brightness level.
Contrast Adjust the brightness first, and then adjust the contrast only if further adjustment is
necessary.
Press the
button to increase the contrast and press the button to decrease the
contrast (Range: 0 ~ 100).
The contrast function adjusts the degree of difference between darkness and lightness
on the screen.
Auto Adjust Use this option to activate automatic setup and adjust the menu.
Dell Pro 2X Adjustable Stand Monitor - E2X25HSM
Brightness / Contrast
Auto Adjust
Input Source
Color
Display
Menu
Audio
Personalize
Others
More Information
Press to adjust the screen automatically.
The following dialog appears on a black screen as the monitor self-adjusts to the current
input:
Auto Adjust allows the monitor to self-adjust to the incoming video signal. After using
Auto Adjustment, you can further tune your monitor by using the Pixel Clock (Coarse)
and Phase (Fine) controls under Display.
NOTE: Auto Adjust does not occur if you press the button while there are no active
video input signals or attached cables.
This option is available only when you are using the analog (VGA) connector.
