2. Install the power-adapter port.
3. Install the system board.
4. Install the I/O board.
5. Install the display assembly.
6. Install the heat sink.
7. Install the fan.
8. Install the wireless card.
9. Install the SSD.
10. Install the memory module.
11. Install the battery.
12. Install the base cover.
13. Follow the procedure in After working inside your computer.
Palm-rest assembly
Removing the palm-rest assembly
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the memory module.
5. Remove the SSD.
6. Remove the wireless card.
7. Remove the fan.
8. Remove the heat sink.
9. Remove the display assembly.
10. Remove the I/O board.
11. Remove the power button.
12. Remove the speakers.
13. Remove the system board.
14. Remove the power-adapter port.
15. Remove the keyboard.
About this task
NOTE:
The system board can be removed with the heat sink attached in order to simplify the procedure and preserve the
thermal bond between the system board and the heat sink.
NOTE: The palm-rest assembly cannot be further disassembled once all the prerequisites are completed. The touchpad is
part of the palm-rest assembly. If the touchpad is malfunctioning and needs to be replaced, the entire palm-rest assembly
must be replaced.
The image below shows the palm-rest assembly after the prerequisites have been completed. After performing the steps
mentioned in the prerequisites, you are left with the palm-rest assembly.
Removing and installing Field Replaceable Units (FRUs)
89
