Connect a power adapter to provide power to your computer.
2. Battery-status light
Indicates the battery-charge status.
Solid white—Battery is charging.
Solid amber—Battery charge is low.
Off—Battery is fully charged.
3. HDMI 2.1 Transition-minimized differential signaling (TMDS) port
Connect to a TV, external display, or another HDMI-in enabled device. Supports video and audio output.
4. USB 40 Gbps port with Power Delivery and DisplayPort
Connect devices, such as external storage devices and printers. Supports USB and DisplayPort which enables you to
connect to an external display using a display adapter. Supports data transfer rates of up to 40 Gbps.
● For computers shipped with AMD Ryzen AI 300 Series processors: Supports DisplayPort 2.1
● For computers shipped with AMD Ryzen 200 Series processors: Supports DisplayPort 1.4a
NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
NOTE: A 40 Gbps-certified cable is required to achieve the maximum performance of 40 Gbps.
NOTE: The USB port is backward compatible with USB 3.2, USB 2.0.
5. Global headset port
Connect headphones or a headset (headphone and microphone combo).
Top
Figure 3. Top view
8
Views of Dell Pro 14 PC14255
