Figure 40. Removing the power button with fingerprint reader
Steps
1. Remove the two screws (M2x2) that secure the power button to the palm-rest assembly.
2. Lift the power button from the slot in the palm-rest assembly.
Installing the power button with a fingerprint reader
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
NOTE:
For computers shipped without a fingerprint reader configuration, the power button installation steps remain the
same.
The following images indicate the location of the power button and provide a visual representation of the installation procedure.
70
Removing and installing Field Replaceable Units (FRUs)
