About this task
The following image indicates the location of the eDP cable and provides a visual representation of the removal procedure.
Figure 84. Removing the eDP cable
Steps
1. Disconnect the eDP cable from the connector (LCD1) on the camera module.
2. Peel away the conductive tape that adheres the eDP cable to the display back cover.
3. Lift the eDP cable away from the computer.
Installing the eDP cable
CAUTION: The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the eDP cable and provides a visual representation of the installation procedure.
Removing and installing Field Replaceable Units (FRUs)
115
