5. Install the display assembly.

6. Install the wireless card.

7. Install the solid state drive.

8. Install the base cover (plastic chassis).

9. Follow the procedure in After working inside your computer.

System board

Removing the system board (for computers shipped with a plastic

chassis)

CAUTION:

The information in this removal section is intended for authorized service technicians only.

Prerequisites

1. Follow the procedure in Before working inside your computer.

2. Remove the base cover (plastic chassis).

3. Remove the memory module.

4. Remove the solid state drive.

5. Remove the wireless card.

6. Remove the fan.

7. Remove the 3-cell battery or the 4-cell battery, whichever is applicable.

8. Remove the heat sink.

NOTE:

The system board can be removed and installed along with the heat sink, when replacing the palm-rest and

keyboard assembly. This simplifies the removal and installation procedure and prevents damage to the thermal bond

between the system board and heat sink.

About this task

The following image indicates the connectors on your system board.

Removing and installing Field Replaceable Units (FRUs)

89
