Steps

After performing the Prerequisites, you are left with the display back-cover and antenna assembly.

Installing the display back-cover and antenna assembly (only for

computers shipped with a plastic chassis)

CAUTION: The information in this installation section is intended for authorized service technicians only.

Prerequisites

If you are replacing a component, remove the existing component before performing the installation procedure.

About this task

The following image indicates the location of the display back-cover and antenna assembly and provides a visual representation

of the installation procedure.

Figure 77. Display back-cover and antenna assembly

Steps

Place the display back-cover and antenna assembly on a flat surface and perform the Next steps to install the display

back-cover and antenna assembly.

Next steps

1. Install the camera.

2. Install the display cable.

3. Install the display panel.

4. Install the display bezel.

88

Removing and installing Field Replaceable Units (FRUs)
