11. Connect the display cable to the connector (LCD) on the system board and close the latch.

Next steps

1. Install the wireless card.

2. Install the solid state drive.

3. Install the base cover (plastic chassis) or the base cover (aluminum chassis), whichever is applicable.

4. Follow the procedure in After working inside your computer.

Display bezel

Removing the display bezel (only for computers shipped with a

plastic chassis)

CAUTION:

The information in this removal section is intended for authorized service technicians only.

Prerequisites

1. Follow the procedure in Before working inside your computer.

2. Remove the base cover (plastic chassis).

3. Remove the solid state drive.

4. Remove the wireless card.

5. Remove the display assembly.

About this task

The following image indicates the location of the display bezel and provides a visual representation of the removal procedure.

Figure 57. Removing the display bezel

Removing and installing Field Replaceable Units (FRUs)

71
