10. Peel back the tape that secures the wireless-antenna cables to the system board.

NOTE: This step applies only to computers shipped with a plastic chassis.

11. Remove the wireless-antenna cables from the routing guides on palm-rest and keyboard assembly.

NOTE: This step applies only to computers shipped with a plastic chassis.

12. Gently lift the palm-rest and keyboard assembly at an angle and remove the palm-rest and keyboard assembly from the

display assembly.

CAUTION: To avoid damaging the display, do not slide the palm-rest and keyboard assembly over the display

assembly.

NOTE: For computers shipped with an aluminum chassis, the display assembly is a Hinge-Up Design (HUD) and cannot

be further disassembled once it has been removed from the computer. If any of the components within the display

assembly is faulty, replace the entire display assembly.

Installing the display assembly

CAUTION:

The information in this installation section is intended for authorized service technicians only.

Prerequisites

If you are replacing a component, remove the existing component before performing the installation procedure.

About this task

The following images indicate the location of the display assembly and provide a visual representation of the installation

procedure.

68

Removing and installing Field Replaceable Units (FRUs)
