NOTE: This step applies only to computers shipped with a power button with fingerprint reader installed.

6. Remove the two screws (M2x3) that secure the I/O board to the palm-rest and keyboard assembly.

7. Carefully slide and remove the I/O board at an angle, from the palm-rest and keyboard assembly, to clear the ports from the

port slots.

Installing the I/O board

CAUTION: The information in this installation section is intended for authorized service technicians only.

Prerequisites

If you are replacing a component, remove the existing component before performing the installation procedure.

About this task

The following images indicate the location of the I/O board and provide a visual representation of the installation procedure.

56 Removing and installing Field Replaceable Units (FRUs)
