NOTE: Ensure that your computer is in Service Mode. If your computer is unable to enter Service Mode,
disconnect the battery cable from the system board. To disconnect the battery cable, follow steps 4 and 5.
4. Disconnect the battery cable from the battery cable connector (BATT1) on the system board.
5. Press and hold the power button for five s to ground the computer and drain the flea power.
Installing the base cover
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the base cover and provide a visual representation of the installation procedure.
Figure 7. Installing the base cover
44
Removing and installing Customer Replaceable Units (CRUs)
