Power adapter
The following table lists the power adapter specifications of your Dell Pro 13 Plus PB13250.
Table 16. Power-adapter specifications
Description Option one Option two Option three
Type
60 W adapter, USB-C 65 W adapter, USB-C 100 W adapter, USB-C
Power-adapter dimensions:
Height
22 mm (0.86 in.) 28 mm (1.10 in.) 26.5 mm (1.04 in.)
Width
55 mm (2.16 in.) 51 mm (2.01 in.) 60 mm (2.36 in.)
Depth
66 mm (2.59 in.) 112 mm (4.41 in.) 122 mm (4.80 in.)
Input voltage
100 to 240 VAC 100 to 240 VAC 100 to 240 VAC
Input frequency
50 Hz x 60 Hz 50 to 60 Hz 50 to 60 Hz
Input current (maximum)
1.70 A 1.70 A 1.70 A
Output current (continuous)
● 20 V/3 A (continuous)
● 15 V/3 A (continuous)
● 9.0 V/3 A (continuous)
● 5.0 V/3 A (continuous)
● 20 V/3.25 A (continuous)
● 15 V/3 A (continuous)
● 9 V/3 A (continuous)
● 5 V/3 A (continuous)
● 20 V/5 A (continuous)
● 15 V/3 A (continuous)
● 9.0 V/3 A (continuous)
● 5.0 V/3 A (continuous)
Rated output voltage
20 VDC/15 VDC/9 VDC/5
VDC
20 VDC/15 VDC/9 VDC/5
VDC
20 VDC/15 VDC/9 VDC/5
VDC
Temperature range:
Operating
0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F) 0°C to 35°C (32°F to 95°F)
Storage
-20°C to 70°C (-4°F to
158°F)
-40°C to 70°C (-40°F to
158°F)
-40°C to 70°C (-40°F to
158°F)
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
Power adapter requirements of Dell Pro 13 Plus PB13250 (for
computers that are shipped with a 3-cell, 45 Wh battery)
NOTE:
If you did not purchase the Dell-branded power adapter that is recommended for your computer, ensure that the
power adapter you use meets the following requirements.
The following table lists the power adapter requirements for your Dell Pro 13 Plus PB13250.
Table 17.
Power adapter requirements
Description Value
Power that is required from a power adapter to achieve optimal
performance.
65 W
Power that charges the computer at a slower speed. Less than 60 W
Specifications of Dell Pro 13 Plus PB13250 21
