Dummy graphics card
Removing the dummy graphics card
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the battery.
5. Remove the heat sink.
About this task
NOTE: The following procedure is applicable for computers that are shipped with an integrated graphics only.
The following images indicate the location of the dummy graphics card and provide a visual representation of the removal
procedure.
Figure 51. Removing the dummy graphics card
86
Removing and installing Field Replaceable Units (FRUs)
