Table 7. Memory specifications(continued)
Description Values
● 64 GB, LPDDR5x, 7467 MT/s, dual-channel (onboard)
External ports and slots
The following table lists the external ports and slots on your Precision 5690.
Table 8. External ports and slots
Description Values
USB ports
● One USB 3.2 Gen 2 Type-C port with DisplayPort 1.4 Alt
Mode
● Two Thunderbolt 4 (40 Gbps) ports with Power Delivery
Audio port
One universal audio port
Video port(s)
● One USB 3.2 Gen 2 Type-C port with DisplayPort 1.4 Alt
Mode
● Two Thunderbolt 4 (40 Gbps) ports with Power Delivery
● One HDMI 2.1 port
Media-card reader
One SD-card slot (optional)
Power-adapter port
Two Thunderbolt 4 (40 Gbps) port with Power Delivery
Security-cable slot
One wedge-shaped lock slot
Internal slots
The following table lists the internal slots of your Precision 5690.
Table 9.
Internal slots
Description Values
M.2
● Two M.2 2230/2280 for solid state drive
NOTE: To learn more about the features of different
types of M.2 cards, search in the Knowledge Base
Resource at Dell Support Site.
Wireless module
The following table lists the Wireless Local Area Network (WLAN) module that is supported on your Precision 5690.
Table 10.
Wireless module specifications
Description Values
Model number
Intel BE200
Transfer rate
Up to 5760 Mbps
Frequency bands supported
2.4 GHz/5 GHz/6 GHz
18 Specifications of Precision 5690
