Figure 28. Installing the battery
Steps
1. Align the screw holes on the battery with the screw holes on the palm-rest and keyboard assembly.
2. Replace the five screws (M2x3) that secure the battery to the palm-rest and keyboard assembly.
Next steps
1. Install the base cover.
2. Follow the procedure in After working inside your computer.
Disconnecting the battery cable
CAUTION: The information in this removal section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
About this task
CAUTION:
Removing the battery resets the BIOS setup settings to default. It is recommended that you note the
BIOS setup settings before removing the battery.
The following image indicates the location of the battery cable and provides a visual representation of the removal procedure.
50
Removing and installing Field Replaceable Units (FRUs)
