32 Part Number: 9291458 11/17
Operation Section 3
N8100B, N8100-BR & N8100NB Operation
The temperature control is used to turn the unit on and
off as well as control the temperature of the cold pan. The
control is located in the machine compartment. To turn the
cold pan off, turn the knob to the off position. The unit must
be turned off when not in use or overnight for defrosting
and cleaning.
If the cold pan is to be used with ice, it is recommended
that the optional perforated bottoms be used. These will
allow ice to melt properly.
These mechanically cooled cold pans are adjusted at
the factory to provide proper operation. However, if it
is necessary to adjust the temperature, turn the knob
clockwise as indicated on the control. Settings are from 1
thru 7 (7 being the coldest).
• Adjustments should be made gradually.
• Several small adjustments will be more effective than
one large adjustment.
• It may take an hour or longer to realize the temperature
change depending on the application and location of
the unit.
N8100-FA Operation
There is a switch on the compressor housing front to turn
the N8100-FA units on and off. The unit must be turned off
when not in use or overnight for defrosting and cleaning.
NOTE: Food in the N8100-FA pans should not be loaded in
such a way as to interfere with the air curtain flowing over
the cold pans.
Defrost Timer
The recommended defrost timer setting is every 2 hours for
15 minutes.
Ruby Tuesday Salad Bar Service and Installation Manual
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
8
DEFROST TIMER
Pressure Control
The temperature is controlled by an adjustable pressure
control located in the machine compartment and
adjustable control has the word COLDER near the knob,
with an arrow to indicate the adjustment direction. This
control is field adjustable and does not require a service
agent. If you have any questions, call an authorized service
agent.
In attempting to adjust the pressure control, you can
do damage to the unit by accidentally adjusting the
differential.
NOTE: Delfield is not responsible for charges incurred while
adjusting the pressure control.
Factory settings are:
• 30 psi (207 kPa) differential
• 80 psi (552 kPa) cut-in
• 50 psi (345 kPa) cut-out
Cut In -
Knob
Controlled
Dierential
