F2000/F17 Series Equipment Stand Service and Installation Manual
For customer service, call (800) 733-8829, (800) 733-8821, Fax (989) 773-3210, www.delfield.com
6
Delfield
™
®
Drawer base equipment stands are designed and pre-set at the
factory to maintain a temperature of 36°F to 40°F (2°C to 4°C). A
solar-powered digital thermometer is located on the front of the
unit to allow monitoring of the drawer housing temperature.
The drawer housing temperature is controlled by a thermostat
located in the machine compartment. Continuous opening and
closing of the drawers will hamper the unit’s ability to maintain
optimum refrigeration temperature. Excess weight on top of the
unit will adversely affect the operation of the drawers.
The cooling coil is coated in epoxy to provide long-lasting service.
However, storing all acidic items, such as peppers and tomatoes
with lids that are sealable and immediately wiping up all spills of
either acid or base items will greatly extend the life of your unit.
Never stand on the unit or its drawers! They are not
designed to hold the weight of an adult, and may
collapse or unit may tip if misused in this manner.
Refrigerator Evaporator Fan Operation
When the refrigerator is initially powered up or immediately
following a power outage the unit will begin cooling after a 3-6
minute delay. During normal operation the evaporator fan pulses
independently of the compressor as dictated by the controller as
follows:
1. During the cooling mode, compressor and evaporator fan run
simultaneously.
2. During the compressor off mode, evaporator fan pulses three
minutes on and three minutes off.
3. During an actual defrost event other than the off-cycle
defrost, compressor stays off but the evaporator fan runs
continuously.
Cooling Cycle Defrost Cycle
Compressor On Compressor Off Compressor Off
Evap Fan
On
Evap Fan
Off
Evap Fan
On
Evap Fan
Off
Evap Fan
On
Evap Fan
Off
X
Cycles On 3-Min, Off
3-Min
X
Electrical connection
Refer to the amperage data on page 3 & 4, the serial tag, your local
code or the National Electrical Code to be sure the unit is connected
to the proper power source. A protected circuit of the correct
voltage and amperage must be run for con nec tion of the line cord,
or permanent connection to the unit.
The on/off switch must be turned to OFF and the
unit disconnected from the power source whenever
performing service, maintenance functions or
cleaning the refrigerated area.
Under no circumstances is a self-contained unit to
be operated without the louvered panel in place.
Installation — Continued
Operation: Refrigerated Base Equipment Stands
Freezer base equipment stands are designed and pre-set at the
factory to maintain a temperature of 0°F to -5°F (-18°C to -21°C)
interior cabinet temperature at 100°F (38°C) ambient room
temperature. Self-contained units have a digital thermometer
installed in the removable louver. The digital thermometer for
remote units is located in the removable access panel.
Freezer Evaporator Fan Operation
The evaporator fan(s) and condenser fan will cycle off and on with
the compressor to conserve energy. The temperature control will
cycle the compressor and condenser fan motor and evaporator
fan motor to maintain box temperature at the control setting.
Cooling Cycle Defrost Cycle
Compressor On Compressor Off Compressor Off
Evap Fan
On
Evap Fan
Off
Evap Fan
On
Evap Fan
Off
Evap Fan
On
Evap Fan
Off
X X X
Freezer Defrost
Self-contained models use hot gas to defrost the evaporator coils.
Remote freezers use electric defrost.
Operation: Freezer Base Equipment Stands
