14
Deleld
style and can be pulled out of the groove in the door and
new gaskets can be “pressed” back into place.
Doors/Hinges
Over time and with heavy use the door hinges may become
loose. If it is noticed that the door is beginning to sag, it may
be necessary to tighten the screws that mount the hinge
brackets to the frame of the cabinet. If the doors are loose
or sagging, this can cause the hinge to pull out of the frame
which may damage both the doors and the door hinges.
In some cases this may require repair by a qualied service
agent or maintenance personnel.
Drain Maintenance
Each cabinet has a drain located inside which removes the
condensation from the evaporator coil and evaporates it
at an external condensate evaporator pan. Each drain can
become loose or disconnected from moving or bumping
the drain. If you notice excessive water accumulation on the
inside of the cabinet, be sure the drain tube is connected from
the evaporator housing to the condensate evaporator drain
pan. If water has collected underneath the cabinet, check the
condensate evaporator drain tube to be sure it is still located
inside the drain pan. Leveling the cabinet is important as it
is designed to drain properly when on a level surface. If your
oor is not level this can also cause drain problems. Be sure
all drain lines are free of obstructions. Typically, food product
is found blocking drain lines causing water to back up and
overow the drain pans.
Drawer Maintenance
Drawer Assembly Cleaning
The drawer assembly is designed to be cleaned easily. Both drawer
and tracks are removable without tools. The drawer tracks are
dishwasher safe or can be cleaned in a sink with detergents and
a soft bristle brush. Drawers and tracks should be cleaned on a
weekly basis.
Remove Drawers
Pull the drawer box out until it stops. Lift up on the drawer front
and pull the drawer box completely out. Using a soft bristle brush,
clean the track on the bottom of the drawer box. When nished,
it should be wiped clean of all food and debris.
Tracks
The drawer box assembly must be removed. Pull the drawer
tracks out until they hit a stop. Locate blue safety clips towards
the back of each drawer track. Blue safety clips have a tab on the
top. Push the tab back until it clicks. Lift up and pull the drawer
tracks all the way out of the
drawer cage. The drawer
tracks are dishwasher
safe or can be cleaned
in a sink with detergents
and a soft bristle brush.
Drawers and tracks should
be cleaned on a weekly basis. Using a soft bristle brush, wash the
track making sure each roller is thoroughly cleaned. The drawer
cage should be cleaned with a soft bristle brush, removing any
food and debris gathered on the bottom ledge. Once it’s cleaned
thoroughly with a soft bristle brush, wipe remaining debris clean
with a soft towel.
Reassembly
Push the drawer tracks into the drawer cage. The blue safety
clip must remain pushed towards the back. Lift up and slide the
drawer track all the way into the drawer cage. The blue safety clip
will lock in place automatically. Once all tracks are replaced, insert
the drawer box. Rest the drawer box bottom track on the front
track roller. Then push the drawer back in place SLOWLY. When the
drawer box is about half way in you will hit a STOP. You must lift
the front of the drawer up approximately ½” (1.3cm) to continue
inward. Clean tracks as often as possible. The cleaner the tracks
are the better they will operate.
tab on top of
blue safety clip
Maintenance, continued
