20 Part Number: 9291455 08/17
Operation Section 3
230-240Volt Export Work Table Controls
EXPORT TEMPERATURE CONTROL
A thermostat controls temperature in the BUC-E, BST-E,
PTB-E base, PTL-E base and rail. They are located in the
machine compartment.
• The thermostat is set at the factory to provide proper
operation at 2.5.
• To adjust the temperature, turn the knob clockwise as
indicated on the control. Settings are from 1 through 9 (9
being the coldest).
• Adjustments should be made gradually.
• Several small adjustments will be more effective than one
large adjustment.
• It may take an hour or longer to realize the temperature
change depending on the application and location of the
unit.
Thermostat Dial
EXPORT 230-240 VOLT PRESSURE CONTROL
Temperature in the PTB-E rail is controlled by an adjustable
pressure control located in the machine compartment and
adjustable control has the word COLDER near the knob, with
an arrow to indicate the adjustment direction. This control is
field adjustable and does not require a service agent. If you
have any questions, call an authorized service agent.
In attempting to adjust the pressure control, you can do
damage to the unit by accidentally adjusting the differential.
NOTE: Delfield is not responsible for charges incurred while
adjusting the pressure control.
Factory settings are:
• 25 psi (207 kPa) differential
• 55 psi (552 kPa) cut-in
• 30 psi (345 kPa) cut-out
Cut In -
Knob
Controlled
Dierential
PTB-E & PTL-E HIGH PRESSURE LIMITING DEVICE
All R404A models have a high pressure limiting device. Under
severe overloading conditions, or in the event of a condenser
fan failure or a plugged or blocked condenser, this device
may shut down the refrigeration system. This device will
automatically reset, but determining the cause of the high
pressure condition should be investigated by a qualified
refrigeration technician.
