Part Number: 9291455 06/19 17
Section 3 Operation
115Volt Work Table Control Assemblies
• Controls are located in the mechanical section behind a
louvered panel.
• The rail power switch is accessible through a hole in the
louvered panel.
Notice
Rail temperature displayed is for refrigeration set point
purposes only. Display does not reflect air or product
temps in unit.
Unit Power Switch
Base
Temperature
Control
Control Assembly For BSTMP Series & BUCMP Series,
Work Table With Or W/o Backsplash
Unit Power Switch
Rail
Temperature
Control
Rail Power
Switch
Base Temperature
Control
Control Assembly For PTBMP Series & PTLV Series,
Refrigerated Pizza Prep Table With Raised or LiquiTec® Rail
Control Assembly For PDLV Series,
Refrigerated Pizza Prep Table With Dual LiquiTec® Rails
AT START UP
1. At initial start-up or anytime power is disconnected, then
reconnected to the unit, the control will go into defrost
mode.
2. The control will enter a DEFROST mode and the display
will read dEF. The compressor and condenser fan as well
as the evaporator fan will remain off until this initial
defrost is complete. This initial defrost cycle may take up
to 35 minutes to complete.
3. The display will continue to read dEF for an additional 30
minutes while the cooling cycle cools the box to the set
temperature.
4. Then the digital thermostat will display box temperature.
5. The temperature control will cycle the compressor,
evaporator fan motor and condenser fan motor to
maintain box temperature at the control setting. For
more information see Work Table Evaporator Fan
Operation on page 16.
Defrost
The temperature control also monitors the evaporator
temperature and will turn off the compressor and condenser
fan motor when needed to allow accumulated frost on the
evaporator to clear. During this defrost cycle, the digital
temperature display will read dEF. After the defrost cycle is
complete, the temperature control will return to a normal
cooling cycle, but the display will continue to read dEF until
the evaporator returns to normal cooling temperatures (up
to 30 minutes).
The electronic temperature controller monitors evaporator
temperature and compressor run time to determine the
proper time for a positive defrost cycle. A defrost cycle
can occur as often as every 60 minutes under extremely
heavy usage. It can last a minimum of 2 minutes. When the
controller enters the defrost mode the compressor is shut
off and will remain off until the evaporator coil temperature
exceeds 41°F (5°C) or the controller reaches a time limit of 75
minutes on a refrigerated unit.
