10 Part Number: 9291455 08/17
Installation Section 2
Model &
Export Option
# of 1/3 Size Pans
In Rail
Adapter Bars
Refrigerated Countertop Prep Rail
CTP8146-NB
CTP8146-NB-E
4 5
CTP8160-NB
CTP8160-NB-E
6 7
Electrical Service
DANGER
Check all wiring connections, including factory terminals,
before operation. Connections can become loose during
shipment and installation.
n
Warning
This appliance must be grounded and all field wiring must
conform to all applicable local and national codes. Refer
to rating plate for proper voltage. It is the responsibility of
the end user to provide the disconnect means to satisfy
the authority having jurisdiction.
• Plug units with R290 refrigerant into a receptacle that is a
minimum of 14” (36cm) above the floor.
• All electrical work, including wire routing and grounding,
must conform to local, state and national electrical codes.
• The equipment must be grounded.
• A separate fuse/circuit breaker must be provided for each
unit.
• The maximum allowable voltage variation is ±10% of the
rated voltage at equipment start-up (when the electrical
load is highest).
• If optional electrical receptacles are mounted in the unit’s
backsplash, they must be wired independently from the
existing unit wiring.
• Check all green ground screws, cables and wire
connections to verify they are tight before start-up.
Ground Fault Circuit Interrupter
Ground Fault Circuit Interrupter (GFCI/GFI) protection is a
system that shuts down the electric circuit (opens it) when it
senses an unexpected loss of power, presumably to ground.
Welbilt does not recommend the use of GFCI/GFI circuit
protection to energize our equipment. If code requires the
use of a GFCI/GFI then you must follow the local code. The
circuit must be dedicated, sized properly and there must
be a panel GFCI/GFI breaker. We do not recommend the
use of GFCI/GFI outlets to energize our equipment as they
are known for more intermittent nuisance trips than panel
breakers.
Model Amps H.P. NEMA Plug Voltage,
Hertz,
Phase
Refrigerated Work Table With Backsplash
18648BSTMP 2.9 0.20
5-15P 115, 60, 1
18660BSTMP 2.9 0.20
18672BSTMP 2.9 0.20
18691BSTMP 4.8 0.25
18699BSTMP 4.8 0.25
186114BSTMP 6.3 0.33
Optional Export Refrigerated Work Table With Backsplash
18648BST-E 2.5 1/4
Varies Per
Destination
230-240,
50, 1
18660BST-E 2.8 1/3
18672BST-E 5.3 1/2
18691BST-E 5.3 1/2
18699BST-E 5.3 1/2
186114BST-E 5.0 3/4
Refrigerated Work Table
18648BUCMP 2.9 0.20
5-15P 115, 60, 1
18660BUCMP 2.9 0.20
18672BUCMP 4.8 0.20
18691BUCMP 4.8 0.25
18699BUCMP 4.8 0.25
186114BUCMP 6.3 0.33
Optional Export Refrigerated Work Table
18648BUC-E 2.5 1/4
Varies Per
Destination
230-240,
50, 1
18660BUC-E 2.8 1/3
18672BUC-E 5.3 1/2
18691BUC-E 5.3 1/2
18699BUC-E 5.3 1/2
186114BUC-E 5.0 3/4
Refrigerated Pizza Prep Table With Raised Rail
18648PTBMP 4.7 0.25
5-15P 115, 60, 1
18660PTBMP 4.7 0.25
18672PTBMP 6.5 (2) .20
18691PTBMP 6.5 (2) .20
18699PTBMP 6.5 (2) .20
186114PTBMP 6.5 (2) .20
Optional Export Refrigerated Pizza Prep Table With Raised Rail
18648PTB-E 2.5 1/4
Varies Per
Destination
230-240,
50, 1
18660PTB-E 2.8 1/3
18672PTB-E 5.3 1/2
18691PTB-E 5.3 1/2
18699PTB-E 5.3 1/2
186114PTB-E 5.0 3/4
Refrigerated Pizza Prep Table With Dual LiquiTec® Rails
18648PDLV 10.1 1/5, 1/3 5-20P 115, 60, 1
18672PDLV 12.7 1/5, 1/2 5-20P 115, 60, 1
Refrigerated Pizza Prep Table With LiquiTec® Rail
18648PTLV 7.0 1/4 5-15P 115, 60, 1
18672PTLV 14.0 1/2 5-20P 115, 60, 1
18699PTLV 14.0 1/2 5-20P 115, 60, 1
Optional Export Refrigerated Pizza Prep Table With LiquiTec® Rail
18648PTL-E
2.5 1/4
Varies Per
Destination
230-240,
50, 1
18672PTL-E
18699PTL-E
