8 Part Number: 9291455 08/17
Installation Section 2
Weight Of Equipment
Standard Model Model with Export
Option
Weight
Refrigerated Work Table With Backsplash
18648BSTMP 18648BST-E 390lbs (177kg)
18660BSTMP 18660BST-E 435lbs (197kg)
18672BSTMP 18672BST-E 495lbs (225kg)
18691BSTMP 18691BST-E 535lbs (243kg)
18699BSTMP 18699BST-E 594lbs (269kg)
186114BSTMP 186114BST-E 685lbs (310kg)
Refrigerated Work Table
18648BUCMP 18648BUC-E 390lbs (177kg)
18660BUCMP 18660BUC-E 435lbs (197kg)
18672BUCMP 18672BUC-E 495lbs (225kg)
18691BUCMP 18691BUC-E 535lbs (243kg)
18699BUCMP 18699BUC-E 594lbs (269kg)
186114BUCMP 186114BUC-E 685lbs (310kg)
Refrigerated Pizza Prep Table With Raised Rail
18648PTBMP 18648PTB-E 520lbs (236kg)
18660PTBMP 18660PTB-E 575lbs (260kg)
18672PTBMP 18672PTB-E 635lbs (288kg)
18691PTBMP 18691PTB-E 770lbs (350kg)
18699PTBMP 18699PTB-E 805lbs (365kg)
186114PTBMP 186114PTB-E 927lbs (420kg)
Refrigerated Pizza Prep Table With Dual LiquiTec® Rails
18648PDLV - 691lbs (313kg)
18672PDLV - 873lbs (396kg)
Refrigerated Pizza Prep Table With LiquiTec® Rail
18648PTLV 18648PTL-E 520lbs (236kg)
18672PTLV 18672PTL-E 635lbs (288kg)
18699PTLV 18699PTL-E 805lbs (365kg)
Refrigerated Countertop Prep Rail
CTP8146-NB CTP8146-NB-E 121lbs (55kg)
CTP8160-NB CTP8160-NB-E 158lbs (72kg)
Clearance Requirements
DANGER
Minimum clearance requirements are the same for
noncombustible locations as for combustible locations.
The flooring under the appliance must be made of a
noncombustible material.
DANGER
Risk of fire/shock. All minimum clearances must be
maintained. Do not obstruct vents or openings.
All Models Back / Sides 1.00” (25mm)
Rail Model Tops 14.00” (36cm)
Caster Model Bottoms 6.00” (15cm)
• Keep the vents clean and free of obstruction.
• Casters or legs must be used and not removed.
Dimensions
Model &
Export Option
Length Depth Height
Refrigerated Work Table With Backsplash
18648BSTMP
18648BST-E
48.00”
(122cm)
31.50”
(80cm)
40.00”
(102cm)
18660BSTMP
18660BST-E
60.00”
(152cm)
18672BSTMP
18672BST-E
72.00”
(183cm)
18691BSTMP
18691BST-E
91.00”
(231cm)
18699BSTMP
18699BST-E
99.00”
(251cm)
186114BSTMP
186114BST-E
114.00”
(290cm)
Refrigerated Work Table
18648BUCMP
18648BUC-E
48.00”
(122cm)
31.50”
(80cm)
36.00”
(91cm)
18660BUCMP
18660BUC-E
60.00”
(152cm)
18672BUCMP
18672BUC-E
72.00”
(183cm)
18691BUCMP
18691BUC-E
91.00”
(231cm)
18699BUCMP
18699BUC-E
99.00”
(251cm)
186114BUCMP
186114BUC-E
114.00”
(290cm)
Refrigerated Pizza Prep Table With Raised Rail
18648PTBMP
18648PTB-E
48.00”
(122cm)
31.50”
(80cm)
42.00”
(107cm)
18660PTBMP
18660PTB-E
60.00”
(152cm)
18672PTBMP
18672PTB-E
72.00”
(183cm)
18691PTBMP
18691PTB-E
91.00”
(231cm)
18699PTBMP
18699PTB-E
99.00”
(251cm)
186114PTBMP
186114PTB-E
114.00”
(290cm)
Refrigerated Pizza Prep Table With Dual LiquiTec® Rails
18648PDLV 48.00”
(122cm)
31.50”
(80cm)
53.67”
(136cm)
18672PDLV 72.00”
(183cm)
Refrigerated Pizza Prep Table With LiquiTec® Rail
18648PTLV
18648PTL-E
48.00”
(122cm)
31.50”
(80cm) Plus 6”
(15cm) Cutting
Board
42.00”
(107cm)
18672PTLV
18672PTL-E
72.00”
(183cm)
18699PTLV
18699PTL-E
99.00”
(251cm)
Refrigerated Countertop Prep Rail
CTP8146-NB
CTP8146-NB-E
46.00”
(117cm)
17.03”
(43cm)
12.55”
(32cm)
CTP8160-NB
CTP8160-NB-E
60.00”
(152cm)
