12
If there is a little wear, sharpen the tool with a file. Sharpen frequently by
collecting a small amount of material. A few strokes of the file are
sufficient to sharpen a slightly worn blade. After every 5 sharpening
operations, check the balance of the tool on a special machine or have it
checked by a specialist workshop. Sharpen severely worn cutting tools
with a sharpening device or have them sharpened by a specialised
service centre. Always check the balance of the tool after sharpening a
heavily used tool.
Angle gear lubrication
To refill the grease in the bevel gear, unscrew the grease channel plug
screw (Fig. E, 1), inject the grease into the centre of the gear housing in
an amount such that it does not cover the thread in the grease channel.
Screw in the screw. Refill the grease regularly after every 10 operating
hours.
Cleaning the air filter
To clean the air filter, close the intake valve (Fig. C, 2; upper lever
position), open the carburettor cover, remove the coarser dirt from around
the filter and pull out the filter. Shake the filter off, blow it out or replace it
with a new one, never rinse it. Insert the clean filter into the filter housing,
close the cover. Clean the filter regularly, after every 10 operating hours.
Carburettor adjustment
The idle speed is adjusted by means of a screw located on the carburettor
(Fig. C, 1). Turning the screw clockwise will increase the idle speed (done
when the engine stalls for no reason when the user lets go of the throttle
trigger), turning the screw counterclockwise will decrease the idle speed
(done when the cutting element rotates even though the engine is running
at idle speed).
Cleaning, replacement, adjustment of spark plugs
To remove the spark plug, disconnect the ignition cable (Fig. A, 1),
unscrew the plug with the supplied spanner. Clean the spark plug with a
spark plug cleaning brush and a clean cleaner (not applicable to spark
plug replacement).
The gap between the electrodes should be between 0.6 and 0.7 mm.
Adjust it with suitable tools.
Screw in the spark plug, connect the ignition cable. It is prohibited to
remove the spark plug while the engine is hot.
Storage and transport
When the appliance is not in use, store it out of the reach of children, in a
dry place, with the fuel tank emptied. The appliance and the other
components mentioned in the delivery note should be transported in such
a way that they are not exposed to harmful environmental conditions such
as humidity, precipitation, pressure that could result in mechanical
damage and other conditions that could have a negative impact on the
appliance.
When transporting the unit, always switch off the
engine, disconnect the spark plug wire and empty
the fuel tank.
Store and transport metal cutting components in a dedicated guard. For
short distances, carry the unit by holding the boom with one hand, at the
balance point of the unit between the sling and the handlebar mount.
12. Spare parts and accessories
Use only original spare parts and accessories recommended by the
manufacturer.
Accessories available for purchase:
- DED87151 - cutting head with line
- DED87152 - cutting disc
- 80Z16151 - fishing line 1,6 mm x 15 m with round cross section
- 80Z20151 - fishing line 1,6 mm x 15 m with round cross section
- 80Z24151 - fishing line 1,6 mm x 15 m in round cross section
- 80Z16152 - fishing line 1,6 mm x 15 m in square cross section
- DEGL06A, DEGL06B, DEGL06C - oils
- BHSZ30 - two-armed adjustable braces
For the purchase of spare parts and accessories, please contact the
Dedra Exim service. Contact details can be found on page 1 of the
manual.
When ordering spare parts, please quote the batch number on the
nameplate together with the part number from the assembly drawing.
During the warranty period, repairs are carried out in accordance with the
terms of the warranty card. Return the faulty product for repair at the place
of purchase (the dealer is obliged to accept the faulty product), send it to
the central Dedra Exim service centre or to the service centre closest to
your place of residence (list of service centres at www.dedra.pl). Kindly
enclose the completed warranty card. After the warranty period has
expired, repairs are carried out by the central service. Send the defective
product to the service centre (shipping costs are paid by the user).
13. Trouble-shooting on your own
Disconnect the unit from the power supply before
attempting to troubleshoot the unit yourself.
Problem
Cause
Solution
Device does
not start
Lack of fuel
Fill the tank with fuel
Fouled or faulty spark plug
Clean or replace spark
plug
Damaged fuel line
Have the unit serviced
Engine failure
Have the machine
serviced
Unit goes out
Idle speed too low
Adjust carburettor
Insufficient fuel in the tank
Fill up fuel tank
Appliance has
reduced power
Spark plug dirty
Clean spark plug
Plant debris wrapped
around the cutting
attachment
Secure the machine and
clean the cutting
attachment
Appliance
makes a
disturbing
noise
Damaged bevel gearbox
Have the machine
serviced
Engine failure
Have the machine
serviced
15. Contents of the package
DED8717: 1. Boom - pcs. 1, 2. Motor with accessories - pcs. 1, 3. steering
wheel - pcs. 1, 4. Cutting element cover - pcs. 1, 5. assembly elements
and accessories - pcs. 6. 2 x head with Ø2,4mm x 2,5m monofilament, 7.
monofilament disc, 8. triple-tooth cutting disc, 9. double-armed carrying
harness, 10. mesh face shield, 11. fuel tank, 12. monofilament 2,4m15m
DED8717A: 1. boom - pcs. 1, 2. motor with accessories - pcs. 1, 3.
steering wheel - pcs. 1, 4. Cutting element cover - pcs. 1, 5. assembly
elements and accessories - pcs. 6. cutting head with Ø2,4mm line 7.
trident cutting disc, 8. two-armed carrying braces
16. Information on disposal of waste equipment
The user of the appliance is obliged, in accordance with environmental
regulations, to carry out proper waste management in accordance with
national legislation.
The used or faulty appliance must not be disposed of with household
waste. The appliance and its accessories consist of different types of
materials, such as metal and plastic. The correct thing to do if you have
to dispose of, reuse or recover parts of your appliance is to take it to a
specialised collection point, where it will be accepted free of charge.
Information on the location of collection points for waste equipment is
provided by local authorities, e.g. on their websites.
Do not dispose of petrol, oil, used oil, oil/petrol mixtures or objects
contaminated with oil, e.g. cloths, in the municipal waste bins. Dispose of
used oil or items contaminated with it in accordance with local guidelines
and hand them over to a recycling centre.
Recycle used packaging.
By disposing of the appliance correctly, you are conserving valuable
resources and avoiding the negative effects on health and the
environment resulting from the possible presence of hazardous:
substances, mixtures and components in the equipment.
Incorrect disposal is subject to penalties under the relevant local
regulations.
Warranty card
for
……………….……………………………
(product name)
Catalogue No: ………………. Lot No.: ..........................
(hereinafter called the product)
Product purchase date : .............
Seller’s stamp
Date and seller’s signature: .................................
User’s statement:
I confirm that I have been informed about the warranty conditions and
the consequences of non-compliance with the guidelines in the
Operating Instructions and the warranty. I am aware of the conditions of
this warranty, which I confirm with my handwritten signature:
............................... .....................................
Date and place User’s signature
