FILTERING VERSION
In case fumes and vapour cannot be
discharged to the outside, the applian-
ce can be used in the ltering mode,
Activated charcoal lters are required in
this operation mode (g. 10). The air re-
cycled through the charcoal lters is then
re-circulated into the kitchen, thanks to
a duct conveying the air on one side of
the cabinet.
MOUNTING THE MOTOR
Only in the case of appliances equip-
ped with internal motor, it is possible to
mount the motor separately from the
hood; in this case, you will need to order
the dhk900 – 989580001 kit.
REMOVING THE GREASE FILTER,
FITTING THE ACTIVATED CHARCO-
AL FILTER
Grease lters and charcoal lters remo-
ving and tting operations shall be carri-
ed out with the downdraft open. To open
the downdraft, push the key .
.
Then remove the front panel by simulta-
neously pulling on the top of each side
(g. 8). The panel will rotate forwards,
thus allowing to reach the grease lters.
Remove the grease lters to reach the
charcoal lters . Charcoal lters shall be
replaced (g. 11) accordingly to actual
use of the Downdraft, in any case at le-
ast once every 6 months.
Caution: the lters protection panel shall
be re-t properly, otherwise the hood
might stop operation.
CONNECTING THE HOOD TO PO-
WER SUPPLY
Thisapplianceisequip-
pedwithaH05VVFwith3x
0,75mm2conductors(neu-
tral,phaseandground)po-
wercord.
It shall be connected to a
220V–240Velectricalmo-
no-phasenetworkthrougha
CEI 60083 approved power
socket, which shall be ac-
cessibleafterinstallation,in
38
compliance with installa-
tionregulations.Wehereby
declineanyliabilityincase
of accidents due to failure
toconnect thehood tothe
groundorincorrectground
connection.The fuseto be
usedshallbe10or16A.In
caseofdamagestothepo-
wercord,pleasecalltheaf-
ter-sale service in order to
avoidanykindofrisk.
ELECTRICAL CONNECTION
This appliance complies with Europe-
an Directives 2006/95/CE (Low Voltage
Directive) and 2004/108/CE (Electroma-
gnetic Compatibility ) .
The hood shall be disconnected from po-
wer supply during installation and main-
tenance operations, while fuses shall be
disconnected or removed. Electric con-
nection shall be completed before tting
the appliance into the cabinet.
Check that:
- Power is adequate
- Power lines are in good conditions.
- Cables diameter is compliant with in-
stallation regulations.
Caution
In case the hood shows any
anomalies, please disconnect
it or remove the fuse corre-
sponding to the appliance po-
wer disconnecting line.
