OPERA UNICA 12 - OPERA UNICA 15 Cod. 420120269 REV. 1.0

The OPERA UNICA series speakers can be used as monitors for small live contests. In

this case, lay them horizontally on the tilted side. Be reminded of the sound coverage

features reported in the relevant section. Use the suitable DSP settings as indicated in

the "DSP preset" table in wedge mode (W1 or FLAT).

WEDGE (MONITORING) USE

The OPERA UNICA models can be wall-mounted in vertical or horizontal position

through the WB-OP12, WB-OP15 accessory, to be used with OPERA UNICA 12 and

OPERA UNICA 15, respectively.

For further details refer to the instructions relevant to this accessory.

WALL-MOUNTING WITH BRACKETS

The OPERA UNICA models can be installed on a truss in vertical or horizontal

position, through the WB-OP12, WB-OP15 accessory, to be used with OPERA UNICA

12 and OPERA UNICA 15, respectively. This accessory allows the use of aliscaff

couplers (not included) for this special conguration.

For further details refer to the instructions relevant to this accessory.

INSTALLATION ON TRUSS WITH BRACKETS AND ALISCAFF COUPLERS

INSTALLATION WITH EYEBOLTS

The speaker can also be installed using eyebolts.

The positioning is shown in the gure on the side,

where the rear eyebolt allows adjusting the nal

angle (MAX 45°).
