8
ENGLISH
DESCRIPTION
“DVX P” is a series two-way passive loudspeakers with of plywood box designed for medium to
large sized rooms.
The loudspeakers of the DVX P series feature passive crossover filters with a slope of 12dB/oct for
the low-pass part, 18dB/oct for the high-pass and a self-resetting thermal protection circuit on the
driver to prevent damages due to protracted overloading.
DVX P8
The passive speaker DVX P8 is equipped with a woofer 8”
(voice coil 2”) and a compression driver 1” (voice coil 1.5”) on
a 90°x70° rotatable plastic CD- horn.
The speaker’s horizontal directivity is 90° and vertical
directivity is 70° by default factory setting.
The speaker has a top handle housing, the 12 M8 threads
and the 2 flypins located on the sides and the back of the
speaker are enabling easy transport and installation.
The speaker has been designed to be used also as stage
monitor (45° angle). By rotating the horn you can maintain the
same coverage angle also when the speaker is used as
monitor.
In the bottom of the box there is a standard pole mount cup
(D36mm) made of aluminium.
DVX P10
The passive speaker DVX P10 is equipped with a woofer 10”
(voice coil 2”) and a compression driver 1” (voice coil 1,5”) on
a 90°x70° rotatable plastic CD- horn.
The speaker’s horizontal directivity is 90° and vertical
directivity is 70° by default factory setting.
The speaker has a top handle housing, the 12 M8 threads
and the 2 flypins located on the sides and the back of the
speaker are enabling easy transport and installation.
The speaker has been designed to be used also as stage
monitor (45° angle). By rotating the horn you can maintain the
same coverage angle also when the speaker is used as
monitor.
In the bottom of the box there is a standard pole mount cup
(D36mm) made of aluminium.
In the bottom of the box there is a standard pole mount cup
(D36mm) made of aluminium.
