Manuel d’utilisation – Owners Manual
9
In a two speaker system with a simple 2 binding post connection:
If you are using bare wire: With the amplifier end terminated and connected: Strip back about 1
cm ( or 1/2 inch) on both Red (+) and Black (-) cables going from the left amplifier output to the left
speaker enclosures. Unscrew the cap of the red and black binding posts on the rear of the enclosure
until you see a little hole.
Insert the wires into the appropriate holes observing polarity. Tighten the binding post cap snugly.
Repeat the process for the right speaker.
Dual Terminals for Bi-amping and bi-wiring:
It is becoming more common for higher-end performance speakers to include dual sets of binding
posts. Models with dual terminals almost al-ways also feature a special type of built-in crossover with
separate "high-pass" and "low-pass" sections.
Speakers with dual sets of terminals work fine when used with a single set of speaker cables. These
come from the factory set up for conventional operation, with "jumpers" installed between the two
sets. These jumpers can be easily removed for bi-amping or bi-wiring.
Pictured below is standard wiring where the straps remain in place. Single amp.
+
-
To the terminal ‘’+’’
Of the amplifier
To the terminal ‘’-‘’
Of the amplifier
Single connection
Mono-amplification
