UK
DATEQ SPL6 Manual Technical specifications
11
Technical specifications
Inputs
Mic (Measurement microphone)......................XLR-3 female. Use only the original DCM-5
microphone
Line (left and right)...........................................XLR-3 female. Electronically balanced.
Maximum input level...............................+18dBu
Input impedance.....................................50kOhm
Commom-mode rejection.......................>86dB
Outputs
Line (left and right)...........................................XLR-3 male. Electronically balanced.
Output impedance..................................50Ohm
Common
Audio
Frequency response...............................5Hz...22kHz @ -1dB
Signal/ noise ratio...................................>80dB
THD+N (IEC-A).......................................<0.06%
Limiter
Threshold................................................70...120dBA (resolution 1dB)
Output correction....................................-50...+18dB (resolution 0,5dB)
Microphone correction............................-40...+18dB (resolution 0,5dB)
Maximum attenuation adjustment...........-6...-50dB (resolution 0,5dB)
Memory
4GB SDHC
365 days * sound pressure information (resolution 1 second)
365 days* event memory
1GB live recording
External connections
External attenuation................................0...-20dB (10kOhm lin. potentiometer)
Signaling and switching outputs..............24V/ 5mA max.
Power supply
Supply voltage........................................100...240V
AC
/ 50Hz
Power usage...........................................15W
Dimensions and weight
Front.......................................................483mm x 45mm (B x H) = 19inch/ 1HE
Depth......................................................175mm
Weight....................................................2.7kg
*Soundlevel data and event logging are stored for maximal 365 days or less when memory is full. The memory system will delete and override oldest data first.
SPL6_151201_V1.0EN
