6
ZA-9250VDAB
Ordercode: D6159
Description of the device
Features
The DAP ZA-9250VDAB is a 250W, 100V 4-zone mixer amplifier and media player with zone volume control.
The 3 microphone/line inputs are equipped with +48 V phantom power and you have a choice of 8
audio sources, including a built-in USB player with two USB inputs (front and rear) and FM/DAB+ tuner with
which you can store up to 10 audio stations (5 FM and 5 DAB+)
The ZA-9250VDAB has several functions. For example, it has a special input for emergency
announcements (such as a fire alarm) that will override all other inputs. It is also equipped with an
adjustable chime function, ducking level control, loop-through connection and a line output that can be
used as a line output, for music only or microphones only. Besides, each zone also has its own line outputs
for being able to connect extra amplifiers, allowing you to extend the PA system if needed.
Outputs
Power amplifier RMS output: 250 W
Output channels: 4
Output mode: Parallel
Output connector: Terminal
Main outputs: 2
Main output connector: 3-pin XLR, RCA
Zone outputs: 4
Zone output connector: Terminal, RCA
Headphone output: 1
Headphone output connector: TRS balanced 6.3 mm
Inputs
Mono inputs: 3
Mono input connector: 3-pin XLR, terminal, TS unbalanced 6.3 mm
Stereo inputs: 3
Stereo input connector: RCA, TRS balanced 3.5 mm
Auxiliary inputs: 1
Auxiliary input connector: RCA, TRS balanced 3.5 mm
Transformer: 100 V
Playback
Supported audio files: MP3, WAV
Supported format: FAT16, FAT32
Maximum storage size: 64 GB
Media input/output: USB-A
Playback functions: Up (Skip), Down (Skip), Play, Pause, Stop, Time, Folder
Audio Specifications
Phantom power: 18 V
Sound Editing
Parametric channel equalizer: 2 bands
Input channel equalizer gain range: 12 dB
Input channel fixed frequencies: 100, 12.000 Hz
Microphone input equalizer gain range: 12 dB
Parametric microphone equalizer: 2 bands
Microphone input fixed frequencies: 100, 12.000 Hz
Speech filter attenuation: 3 dB
Speech filter frequency: 300 Hz
