12
ZA-9250VDAB
Ordercode: D6159
Gain level control – Mic 1
Adjust input level for Mic 1.
Combo input – Mic 1
Combo input for channel 1. Accepts balanced or unbalanced inputs.
Call Trigger terminal connector
Connect both terminals to a trigger button in order to activate chime.
Mic 1 terminal connector IN
Terminal input for Mic 1. Accepts balanced or unbalanced inputs.
Zone 4 100V terminal connector
Connect the main feed cable (+) from your 100V speaker to the 100V terminal. Connect the
common cable (-) from your speaker to the 0 terminal.
Zone 3 100V terminal connector
Connect the main feed cable (+) from your 100V speaker to the 100V terminal. Connect the
common cable (-) from your speaker to the 0 terminal.
Zone 2 100V terminal connector
Connect the main feed cable (+) from your 100V speaker to the 100V terminal. Connect the
common cable (-) from your speaker to the 0 terminal.
Zone 1 100V/8Ω terminal connector
If you connect a 100V speaker, connect the main feed cable (+) to the 100V terminal and the
common cable (-) to the 0 terminal.
If you connect a low impedance speaker, then connect the main feed cable (+) to the 8Ω terminal
and the common cable (-) to the 0 terminal.
NOTE: Do not connect the 100V and 8Ω speakers at the same time.
Call Only terminal connector
Use this output as an extra zone where announcements can be heard, but not music.
24V DC IN terminal connector
This input can be used in mobile applications, such as boats where 115 or 230V AC is not available or
in applications that must continue to operate in case of power shortage. When a 24V DC battery is
connected, the unit will operate on the supplied DC voltage. The amplifier has a built-in charger,
which charges the connected battery (lead acid battery only). Make sure, the amplifier is
connected to 115 V AC or 230 V AC to enable charging.
XLR balanced connector OUT
Use this connector to provide a dedicated output source for another device.
Mix Out/Speech Only/Music Only
Master output can be connected to a telephone coupler, so that callers can listen to music when
they are put on hold. Move the switch to one of the 3 available options:
• Mix Out
• Music Only
• Speech Only
Mix Out: Set the switch to Line Out. All mixed inputs (microphone/line, emergency and music) will be
audible.
Music Only: Set the switch to Music Only. Now, the XLR balanced output (52) becomes an extra
dedicated music output source, available for another external device. The outputs (31/32/33) will be
audible. All the other inputs, including Telephone/Emergency/100V will not be sent to the output.
Speech Only: Only the microphone input will be audible at the XLR balanced output (52).
