3.4. Product Specifications

Model: PA-5500SA

Inputs:

Mono Inputs 1

Mono Input Connector 3-pin XLR

Mono Input Gain Range 10dB

Stereo Inputs 4

Stereo Input Connector RCA

Auxiliary Inputs 2

Auxiliary Input Connector RCA / TRS balanced 3.5 mm

Transformer N/AV

Outputs:

Power Amplifier RMS Output 240W

Power Amplifier Peak Output 460W

Output per Channel into 8 ohms at 1 kHz 240W

Bridge Output 100 V 240W

Output Channels 2

Output Mode Bridge / Stereo

Output Connector 3-pin XLR / Terminal

Main Outputs 2

Main Output Connector Phoenix / RCA

Playback:

Supported Audio Files AAC/AAC+ / ALAC / APE / FLAC / MP3 / WAV

Supported Format exFAT / FAT16 / FAT32

Maximum Storage Size 128 GB

Media Input/Output USB-A

USB Type 2.0

Playback Functions Up (Skip) / Down (Skip) / Play / Pause / Stop

Audio Specifications:

THD Level < 0.1%

Signal-to-noise Ratio > 100 dB

Slew Rate 14V/μs

Amp Technology Class D

Damping Factor 300:1

Frequency Response Minimum 20Hz

Frequency Response Maximum 20000Hz

Phantom Power No

Wireless Specifications:

Bluetooth Version 5.0

Bluetooth Classification 2

Bluetooth Audio Profile aptX HD 

Bluetooth Range 15m

10

c

Product code: D6176

PA-5500SA
