5
PA-530DAB
Ordercode: D6156
Description of the device
Features
The DAP PA-530DAB is a compact 30 W, 100 V/8Ω mono mixer amplifier with 5 selectable sources and 2
microphone inputs. Both microphone inputs are equipped with phantom power and can also be
selected as line input. The integrated speech filter can be applied to improve audibility. The PA-530DAB
has a line input on the rear and an easy accessible Mini-Jack input on the front for connecting MP3
players or mobile devices. It also has a built-in USB audio player and FM/DAB+ tuner with a large LCD
screen that displays the active source, tuner information and ID3 tags. The built-in FM/DAB+ tuner can
store up to 10 preset stations (5 FM and 5 DAB+). This 100 V mixer amplifier is suitable for small installations
up to 30 W. It is designed to support a PA system that is intended for intercommunication or background
music in public areas such as convention halls, shopping malls, dining halls, auditoriums and recreational
areas. These amplifiers have an integrated protection to protect against overload and short circuit of the
output. This results in very high reliability and easy installations without additional audio processors.
Outputs
• Power amplifier RMS output: 30 W
• Output per channel at 70/100 V at 1 kHz: 30 W
• Output channels : 1
• Output mode : Parallel
• Output connector: Terminal
• Headphone output: 1
• Headphone output connector: TRS balanced 6.3 mm
Inputs
• Mono inputs: 2
• Mono input connector: 3-pin XLR, TS unbalanced 6.3 mm
• Stereo inputs: 1
• Stereo input connector: TRS balanced 3.5 mm
• Auxiliary inputs: 1
• Auxiliary input connector: RCA
• Transformer: 100 V
Playback
• Supported audio files: MP3, WAV
• Supported format: FAT16, FAT32
• Maximum storage Size: 64 GB
• Media input/output: USB-A
• Playback functions: Program, Repeat, Continuous , Up (Skip), Down (Skip), Play, Pause, Stop, Time,
Folder
Audio Specifications
• Phantom power: 18 V
Sound Editing
• Parametric main equalizer: 2 bands
• Main output equalizer gain range: 12 dB
• Main output fixed frequencies: 100, 12.000 Hz
• Speech filter attenuation: 6 dB
• Speech filter frequency: 300 Hz
Wireless Specifications
• FM frequency start: 87,5 MHz
• FM frequency end: 108 MHz
• FM antenna impedance: 75 Ω
• DAB+ frequency start: 174 MHz
• DAB+ frequency end: 230 MHz
