INSTALLATION & SERVICE MANUAL FOR PROFESSIONALS
Installation: Calibration of airow
en
6 Compare the ΔPa value on
the manometer with the P3 - > P4 value,
noted as described on page 37.
Einstellwerte / Calibration / Calibrazione
[Pa]
[m³]
[m³]
[Pa]
P1 P2
P3 P4
54
50
171
180
7 Press and hold the alarm reset (E) and
adjust the exhaust air up (D) or down (B)
until the measured ΔPa value approaches
as closely as possible the P3 - > P4 value
noted on the label.
Strong wind bueting the building may
aect the adjustment of the unit.
100%
2
1
4
3
MON - SUN
100%
2
1
4
3
MON - SUN
A
B C
D
E
8 Connect the ΔPa meter (manometer) across the exhaust air direction P1 - > P2
one more time. Check the measured ΔPa value as it may have changed due to the
adjustment on the exhaust side. Make an adjustment if necessary.
9 Check the airow in all rooms and adjust the airow rate by opening/closing the
valves in the dierent rooms.
10 Reconnect the ΔPa meter (manometer)
to check the measured ΔPa value on both
the supply and exhaustsides.
Note the measured values on the label.
Airow
Einstellwerte / Calibration / Calibrazione
020
30
10
40 60 80 100 120 140 160 180 200 220 240
40
50
60
70
80
20
0
[Pa] [m³]
[m³][Pa]
P1 P2
P3 P4
P1-P2
P3-P4
Airow
Einstellwerte / Calibration / Calibrazione
020
30
10
40 60 80 100 120 140 160 180 200 220 240
40
50
60
70
80
20
0
[Pa] [m³]
[m³][Pa]
P1 P2
P3 P4
P1-P2
P3-P4
Airow
Einstellwerte / Calibration / Calibrazione
020
30
10
40 60 80 100 120 140 160 180 200 220 240
40
50
60
70
80
20
0
[Pa] [m³]
[m³][Pa]
P1 P2
P3 P4
P1-P2
P3-P4
54
50
171
180
56
51
11 Press and hold the fan button (B) and
weekly program button (D) for ve sec-
onds until the LED stops ashing.
The unit is now calibrated.
+
5 Sec.
A
B C
D
E
Note:
The adjustment routine above only describes the rst, indicative part of the system's
adjustment The following must also be taken into account:
• adjust the valves in all rooms until the required airow for each room has been achieved.
• check the main airows according to the instructions earlier in this procedure, as major
valve adjustment may greatly aect the main airow.
• during regulation, it must be ensured that the extract airow is always at least 5% higher
than the supply airow in order to create conditions for mass balance in the system.
!
