Pressing [OK] for more than 1 s enters Adjust mode. In Adjust mode, it is possible to make fast adjustment by pressing [▵] [▿] com-

bined with [OK].

Press [▵] [▿] to change value. Press [OK] to shift between digits quickly.

To exit Adjust mode, press [OK] more than 1 s again with changes saving or press [Back] without changes saving.

Operation keys

A yellow indicator light above the operation keys indicates the active key.

[Hand On]: Starts the motor and enables control of the drive via the LCP.

[O/Reset]: The motor stops. If in alarm mode, the motor resets.

[Auto On]: The drive is controlled either via control terminals or serial communication.

[Potentiometer] (LCP12): The potentiometer works in 2 ways depending on the mode in which the drive is running.

In auto-on mode, the potentiometer acts as an extra programmable analog input.

In hand-on mode, the potentiometer controls local reference.

4.2 Programming on Automatic Motor Tuning (AMT)

Run AMT to optimize compatibility between the drive and the motor in VVC

mode.

The drive builds a mathematical model of the motor for regulating output motor current thus enhancing motor performance.

Run this procedure on a cold motor for best results. To run AMT, use the numeric LCP (NLCP). There are 2 AMT modes for drives.

N O T I C E

In mode 2, the rotor rotates during the AMT progress.

Do not add any load on the motor in this AMT progress.

4.2.1 Mode 1

Procedure

Enter the main menu.

Go to parameter group 1-** Load and Motor.

Press [OK].

Set motor parameters using nameplate data for parameter group 1-2* Motor Data.

Go to parameter 1-29 Automatic Motor Tuning (AMT).

Press [OK].

Select [2] Enable AMT.

Press [OK].

The test runs automatically and indicates when it is complete.

4.2.2 Mode 2

Procedure

Enter the main menu.

Go to parameter group 1-** Load and Motor.

Press [OK].

Set motor parameters using nameplate data for parameter group 1-2* Motor Data.

Go to parameter 1-29 Automatic Motor Tuning (AMT).

Press [OK].

Select [3] Complete AMT with Rotating motor.

Press [OK].

The test runs automatically and indicates when it is complete.

Programming

VLT® Micro Drive FC 51

Operating Guide
