2
1
e30bh486.10
7 6 5 4 3 2 1
7 6 5 4 3 2 1
Illustration 63: Connections between the Optical Fiber Board and ASIC Board FR10–FR11, and FR13
1
Power unit (ASIC board)
2
Optical fiber board on control unit
3
1
2
e30bh490.10
T W VU
T W VU
W V U7 6 5 4 3 2 1T7 6 5 4 3 2 1T
7 6 5 4 3 2 1
7 6 5 4 3 2 1
Illustration 64: Connections between the Star-coupler Board, ASIC Boards, and Feedback Boards, FR12 and FR14
1
Power unit 1 (ASIC board and Feedback board)
2
Power unit 2 (ASIC board and Feedback board)
3
Star-coupler board on control unit
Table 22: Terminals on Optical Cable Adapter Board/Star-coupler Board, ASIC Boards, and Feedback Boards
Terminal
Description
ASIC board of Power unit 1/Power unit 2 (FR12 and FR14)
1
Gate control enable
2
Phase U control
3
Phase V control
4
Phase W control
AQ468246143802en-000201 / DPD00888 | 77Danfoss A/S © 2023.09
Control Unit
VACON® NXP IP00 Drive Modules
Operating Guide
