4
TABLE 2 - TECHNICAL SPECIFICATIONS
All technical specifications are subject to change without notice.
RUBIKORE 2 6 8 ON-WALL CINEMA
Frequency Range 50 - 26,000 Hz ±3 dB 38 - 34,000 Hz ±3 dB 38 - 34,000 Hz ±3 dB 59 - 34,000 Hz ±3 dB 49 - 34,000 Hz ±3 dB
Sensitivi 87 dB @ 1 m for 2.83 V 88.5 dB @ 1 m for 2.83 V 90.5 dB @ 1 m for 2.83 V 88.5 dB @ 1 m for 2.83 V 89 dB @ 1 m for 2.83 V
Nominal impedance 4 ohm 4 ohm 4 ohm 4 ohm 4 ohm
Maximum SPL 107 dB 110dB 112 dB 108 dB 111 dB
Crossover frequency 2,800 Hz 800 / 2,600 / 14,000 Hz
500 / 800 / 2,400 /
14,000 Hz
2,900 / 14,000 Hz 2,800 / 14,000 Hz
Crossover principle 2-way 2½ + ½-way 2½ + ½ + ½-way 2 + ½-way 2 + ½-way
Recommended amplifier
power
40 - 150 Wa 40 - 200 Wa 40 - 250 Wa 20 - 150 Wa 40 - 200 Wa
High frequency driver(s)
1 x 29 mm low loss so
dome
17 x 45 mm planar magne-
tostatic tweeter
1 x 29 mm low loss so
dome
17 x 45 mm planar magne-
tostatic tweeter
1 x 29 mm low loss so
dome
17 x 45 mm planar magne-
tostatic tweeter
1 x 29 mm low loss so
dome
17 x 45 mm planar magne-
tostatic tweeter
1 x 29 mm so dome
High frequency diaphragm So woven fabric
Planar magnetostatic
So woven fabric
Planar magnetostatic
So woven fabric
Planar magnetostatic
So woven fabric
Planar magnetostatic
So woven fabric
Low/Mid frequency
driver(s)
1 x 6½ inch 2 x 6½ inch 3 x 6½ inch 1 x 6½ inch 2 x 6½ inch
Low/Mid frequency
diaphragm
Clari Cone paper and
wood fibre
Clari Cone paper and
wood fibre
Clari Cone paper and
wood fibre
Clari Cone paper and
wood fibre
Clari Cone paper and
wood fibre
Connection input(s) Bi-wire / Bi-amp Bi-wire / Bi-amp Bi-wire / Bi-amp Single wire Bi-wire / Bi-amp
Enclosure pe Bass reflex Bass reflex Bass reflex Bass reflex Bass reflex
Bass reflex tuning
frequency
44 Hz 34 Hz 33 Hz 49 Hz 36 Hz
Other features N/A N/A N/A
Rotatable Hybrid Tweeter
module
Rotatable Hybrid Tweeter
module
Recommended placement Stand / Shelf Floor Floor On-wall / Shelf Stand / Shelf
Recommended distance
from rear wall
20 - 120 cm 20 - 180 cm 25 - 180 cm 0 - 30 cm 5 - 100 cm
Dimensions (H x W x D)
350 x 195 x 335 mm
13.9 x 7.7 x 13.3 inches
990 x 200 x 380 mm
39.1 x 7.9 x 15.0 inches
1100 x 220 x 444 mm
43.5 x 8.7 x 17.6 inches
465 x 278 x 142 mm
18.4 x 11.0 x 5.6 inches
197 x 581 x 400 mm
7.7 x 22.8 x 15.7 inches
Weight incl. grille
9.5 kg
20.9 lb
23 kg
50.7 lb
30 kg
66.1 lb
8.5 kg
18.7 lb
16 kg
35.2 lb
Shipping weight
10.5 kg
23.1 lb
25 kg
55.1 lb
33 kg
72.7 lb
9.5 kg
20.9 lb
17.5 kg
38.5 lb
Finishes
Black High Gloss
Maroon High Gloss
Natural Walnut
White High Gloss
Black High Gloss
Maroon High Gloss
Natural Walnut
White High Gloss
Black High Gloss
Maroon High Gloss
Natural Walnut
White High Gloss
Black High Gloss
Natural Walnut
White High Gloss
Black High Gloss
Natural Walnut
White High Gloss
Accessories
Manual
Rubber Feet
Polishing cloth (high gloss
finish only)
Front Grille
Manual
Polishing cloth (high gloss
finish only)
Front Grille
Premium Spike Set
Manual
Polishing cloth (high gloss
finish only)
Front Grille
Premium Spike Set
Manual
Rubber Feet
Polishing cloth (high gloss
finish only)
Front Grille
Manual
Rubber Feet
Polishing cloth (high gloss
finish only)
Front Grille
Spike thread size M8 M8 M8 N/A N/A
