Air Conditioner Service Manual
81
8. THERMISTOR TEMPERATURE CHARACTERISTICS
1. Indoor unit and outdoor exchange temperature and outside air temperature sensor temperature characteristics
TEMP.
(℃)
R min
(k Ohm)
R(t)
(k Ohm)
R max
(k Ohm)
TEMP.
(℃)
R min
(k Ohm)
R(t)
(k Ohm)
R max
(k Ohm)
TEMP.
(℃)
R min
(k Ohm)
R(t)
(k Ohm)
R max
(k Ohm)
-30
60.343
64.104
68.080
21
5.716
5.846
5.977
72
0.974
1.010
1.047
-29
57.157
60.666
64.375
22
5.498
5.620
5.742
73
0.944
0.980
1.016
-28
54.139
57.413
60.870
23
5.290
5.404
5.518
74
0.917
0.952
0.988
-27
51.301
54.355
57.579
24
5.091
5.198
5.305
75
0.890
0.924
0.959
-26
48.630
51.480
54.487
25
4.900
5.000
5.100
76
0.864
0.897
0.931
-25
46.115
48.776
51.582
26
4.713
4.811
4.909
77
0.839
0.871
0.904
-24
43.748
46.232
48.850
27
4.533
4.630
4.727
78
0.814
0.846
0.879
-23
41.517
43.836
46.279
28
4.362
4.457
4.552
79
0.791
0.822
0.854
-22
39.415
41.581
43.861
29
4.199
4.292
4.386
80
0.769
0.799
0.830
-21
37.432
39.456
41.585
30
4.042
4.133
4.225
81
0.746
0.776
0.807
-20
35.581
37.473
39.462
31
3.892
3.982
4.072
82
0.725
0.754
0.784
-19
33.798
35.565
37.421
32
3.748
3.836
3.925
83
0.705
0.733
0.762
-18
32.134
33.785
35.519
33
3.611
3.697
3.784
84
0.685
0.713
0.742
-17
30.561
32.105
33.725
34
3.479
3.564
3.649
85
0.666
0.693
0.721
-16
29.077
30.520
32.033
35
3.353
3.436
3.520
86
0.647
0.674
0.701
-15
27.673
29.023
30.437
36
3.232
3.313
3.395
87
0.629
0.655
0.682
-14
26.347
27.609
28.931
37
3.116
3.195
3.275
88
0.613
0.638
0.664
-13
25.092
26.273
27.508
38
3.004
3.082
3.161
89
0.595
0.620
0.646
-12
23.905
25.010
26.165
39
2.898
2.974
3.051
90
0.580
0.604
0.629
-11
22.782
23.816
24.896
40
2.795
2.870
2.946
91
0.563
0.587
0.611
-10
21.720
22.687
23.697
41
2.697
2.770
2.844
92
0.549
0.572
0.596
-9
20.713
21.618
22.562
42
2.604
2.675
2.748
93
0.534
0.557
0.580
-8
19.759
20.607
21.490
43
2.513
2.583
2.654
94
0.520
0.542
0.565
-7
18.855
19.649
20.475
44
2.426
2.494
2.564
95
0.506
0.528
0.550
-6
17.999
18.742
19.515
45
2.343
2.410
2.478
96
0.493
0.514
0.536
-5
17.187
17.883
18.606
46
2.263
2.328
2.395
97
0.480
0.501
0.522
-4
16.416
17.068
17.745
47
2.186
2.250
2.315
98
0.468
0.488
0.509
-3
15.685
16.296
16.930
48
2.111
2.174
2.238
99
0.456
0.476
0.497
-2
14.991
15.563
16.156
49
2.041
2.102
2.164
100
0.444
0.464
0.484
-1
14.332
14.868
15.423
50
1.972
2.032
2.093
101
0.433
0.452
0.472
0
13.766
14.270
14.792
51
1.906
1.965
2.025
102
0.422
0.441
0.460
1
13.111
13.582
14.069
52
1.844
1.901
1.959
103
0.412
0.430
0.449
2
12.546
12.987
13.443
53
1.783
1.839
1.896
104
0.401
0.419
0.437
3
12.008
12.422
12.849
54
1.724
1.779
1.835
105
0.391
0.409
0.427
4
11.497
11.885
12.284
55
1.668
1.721
1.776
106
0.381
0.399
0.416
5
11.012
11.375
11.749
56
1.614
1.666
1.719
107
0.372
0.388
0.406
6
10.548
10.889
11.239
57
1.562
1.613
1.665
108
0.362
0.379
0.395
7
10.109
10.428
10.756
58
1.512
1.562
1.613
109
0.353
0.369
0.386
8
9.689
9.988
10.295
59
1.463
1.512
1.562
110
0.344
0.360
0.376
9
9.289
9.570
9.858
60
1.417
1.465
1.514
111
0.335
0.351
0.367
