Air Conditioner Service Manual
27
2) Handle unit transportation with care, the unit should not be carried by only one person if it is more than
20kg.
3) When installing the indoor unit and outdoor unit, a sufficient fixing bolt must be installed, make sure the
installation supporter is firm.
4) Ware safety belt if the height of working is above 2m.
5) Use equipped components or appointed components during installation.
6) Make sure no foreign objects are left in the unit after finishing installation.
Improper installation may lead to fire hazard, explosion, electric shock or injury.
5.3.3 Reminding
WARNING!
(1) Install the indoor unit in a location which can withstand a load of at least five times the weight of the main
unit and which will not amplify sound or vibration.
(2) If the installation location is not strong enough, the indoor unit may fall and cause injuries.
(3) If the job is done with the panel frame only, there is a risk that the unit will come loose. Please take care.
5.3.4 Diagram of Unit Installation Space and Location
5.3.4.1 Diagram of installation space and location for outdoor unit
Notice: for best performance of the outdoor unit, make sure its installation space conforms to the following
installation dimensions.
（
1
）
When one outdoor unit is to be installed.
