Model B
1. Press the circular positon to open the two
screw covers, then remove the two screws.
2.Hold and open the air grille, then take out
the air filter.
a. Hold the upper edge of the filter with both
hands. Gently turn and lift until the upper
edge is free from the wire rope.
b. Lift the filter and move it forward slightly
until the filter is separated from the 4 wire
ropes.
c. Move the filter to the right until it is sepa-
rated from the air grille , and then the filter
can be taken out.
Page 13
a
b
c
Screw Cover
Air Filter
3. Clean the air filter
Dust will accumulate on the filter along with
the unit operation, and need to be removed
from the filter,or the unit would not function
eectively. Clean the filter every two weeks
when you use the unit regularly. Clean the air
filter with a vacuum cleaner or water.
a. The air intake side should face up when
using a vacuum cleaner.
b. The air intake side should face down when
using clean water.
For excessive dusts, use a soft brush and
natural detergent to clean it and dry in a cool
place.
CAUTION
• Do not dry out the air filter under direct
sunshine or with fire.
• The air filter should be installed before the
unit body installation.
4. Re-install the air filter.
5. Press “UP” button on the remote controller
to reset the air grille. (Applicable to model A)
Re-install the air grille by fixing the two
screws and close the two screw covers.
(Applicable to model B)
