3P130767-4K English 1
With DX coil & Humidifier With DX coil
VKM50GBMV1 VKM50GBV1
VKM80GBMV1 VKM80GBV1
VKM100GBMV1 VKM100GBV1
Total Heat Exchanger
Heat Reclaim Ventilator -with DX Coil-
Operation
manual
CONTENTS
ILLUSTRATIONS (figure)...........................................[1][2]
1 SAFETY PRECAUTIONS ................................................1
2 WHAT TO DO BEFORE OPERATION .............................3
3 OPERATION PROCEDURE ............................................6
4 MAINTENANCE (for a qualified service person only) ......9
5 TROUBLE SHOOTING ..................................................10
6 AFTER-SALES SERVICE AND WARRANTY................12
The original instructions are written in English. All other
languages are translations of the original instructions.
Important information regarding the refrig-
erant used
This product contains fluorinated greenhouse gases covered by
the Kyoto Protocol.
Refrigerant type: R410A
GWP
(1)
value: 1975
(1)
GWP = global warming potential
Periodical inspections for refrigerant leaks may be required
depending on European or local legislation.
Please contact your local dealer for more information.
1 SAFETY PRECAUTIONS
To gain full advantage of the Heat Reclaim Ventilator unit’s func-
tions and to avoid malfunction due to mishandling, please read
this operation manual carefully before use. This product comes
under the term “appliances not accessible to the general public”.
• This manual classifies the precautions into WARNINGS
and CAUTIONS. Be sure to follow all the precautions
below: They are all important for ensuring safety.
WARNING ...............Indicates a potentially hazardous situ-
ation which, if not avoided, could result
in death or serious injury.
CAUTION
................Indicates a potentially hazardous situa-
tion which, if not avoided, may result in
minor or moderate injury. It may also be
used to alert against unsafe practices.
• After reading, keep this manual in a convenient place so
that you can refer to it whenever necessary. If the equip-
ment is transferred to a new user, be sure also to hand
over the manual.
WARNING (During Operation)
• Be aware that prolonged, direct exposure to cool or
warm air from the Heat Reclaim Ventilator unit, or to air
that is too cool or too warm can be harmful to your
physical condition and health.
• Do not place objects, including rods, your fingers, etc.,
in the air inlet or outlet.
Injury may result due to contact with the Heat Reclaim Venti-
lator unit’s highspeed fan blades.
• Do not use the Heat Reclaim Ventilator unit in the atmo-
sphere contaminated with oil vapor, such as cooking oil
or machine oil vapor.
Oil vapor may cause crack damage to the Heat Reclaim
Ventilator unit, electric shocks, or a fire.
• Do not use the Heat Reclaim Ventilator unit in places
with excessive oily smoke, such as cooking rooms, or in
places with flammable gas, corrosive gas, or metal dust.
Using the Heat Reclaim Ventilator unit in such places may
cause a fire or Heat Reclaim Ventilator unit failures.
• Do not use flammable materials (e.g., hairspray or insecticide)
near the Heat Reclaim Ventilator unit. Do not clean the Heat
Reclaim Ventilator unit with organic solvents such as paint thinner.
The use of organic solvents may cause crack damage to the
Heat Reclaim Ventilator unit, electric shocks, or a fire.
• To avoid electric shocks, do not operate with wet hands.
• Open the windows and ventilate the room if flammable
gas is leaked.
Insufficient ventilation when the unit is turned on or off may
cause an explosion from sparks at the electrical connection.
• Do not wash the Heat Reclaim Ventilator unit with water,
as this may result in electric shocks or a fire.
(Not including air filters, etc.)
• Be sure to stop the unit and turn off the power when
cleaning or inspecting it.
As the fan is rotating at high speed, it will cause injury.
• Never inspect or service the unit by yourself.
Ask a qualified service person to perform this work. (The
qualified service person)
• Beware of a fire in case of refrigerant leakage.
If the Heat Reclaim Ventilator unit is not operating correctly, i.e. not
generating cool or warm air, refrigerant leakage could be the
cause. Consult your local dealer for assistance. The refrigerant
used for the Heat Reclaim Ventilator unit is safe and normally does
not leak. However, if the refrigerant leaks and gets in contact with a
naked burner, heater or cooker, it may generate hazardous com-
pounds. Turn off the Heat Reclaim Ventilator unit and call your local
dealer. Turn on the Heat Reclaim Ventilator unit after the qualified
service person makes sure to confirm that the leakage is repaired.
• Consult your local dealer if the Heat Reclaim Ventilator unit sub-
merges owing to a natural disaster, such as a flood or typhoon.
Do not operate the Heat Reclaim Ventilator unit in that case, or
otherwise a malfunction, electric shocks, or a fire may result.
• Start or stop the Heat Reclaim Ventilator unit with the remote
controller. Never use the power circuit breaker for this purpose.
Otherwise, it may cause a fire or water leakage. Further-
more, if an automatic restart control is provided against
power failure and the power is recovered, the fan will rotate
suddenly and may cause injury.
• Consult your local dealer regarding cleaning the inside
of the Heat Reclaim Ventilator unit.
Improper cleaning may cause breakage of plastic parts,
water leakage and other damage as well as electric shocks.
CAUTION (During Operation)
• Do not use the Heat Reclaim Ventilator unit for pur-
poses other than those for which it is intended.
Do not use the Heat Reclaim Ventilator unit for cooling preci-
sion instruments, food, plants, animals or works of art as
this may adversely affect the performance, quality and/or
longevity of the object concerned.
• Do not place appliances that produce naked flames in
places exposed to the airflow from the Heat Reclaim Ven-
tilator unit as this may impair combustion of the burner.
• Do not place heaters directly below the Heat Reclaim
Ventilator unit, as resulting heat can cause deformation.
• Be sure that children, plants or animals are not exposed
directly to airflow from the Heat Reclaim Ventilator unit,
as adverse effects may ensue.
• Do not place flammable sprays or operate spray con-
tainers near the Heat Reclaim Ventilator unit or indoor
intake and outlet grills as this may result in a fire.
01_EN_3P130767-4K.fm 1 ページ ２０１３年３月２１日 木曜日 午前１１時５０分
