RMXS112~160E8V1B
Super Multi Plus System air conditioner
4PW40721-1A
Installation manual
1
CONTENTS Page
1. Safety considerations.................................................................1
2. Introduction ................................................................................2
2.1. System layout .............................................................................. 2
2.2. Combination................................................................................. 2
2.3. Standard supplied accessories.................................................... 3
2.4. Optional accessories ................................................................... 3
2.5. Technical and electrical specifications......................................... 3
3. Before installation.......................................................................3
3.1. Precautions for R410A................................................................. 3
3.2. Installation.................................................................................... 3
3.3. Handling....................................................................................... 3
4. Selecting installation site............................................................4
5. Precautions on installation .........................................................4
5.1. Installation method for prevention of falling over.......................... 5
5.2. Method for removing transportation stay ..................................... 5
5.3. Method for installing drain piping ................................................. 5
6. Installation servicing space ........................................................5
7. Refrigerant pipe size and allowable pipe length.........................6
7.1. Selection of piping material.......................................................... 6
8. Precautions on refrigerant piping ...............................................6
8.1. Cautions for brazing..................................................................... 7
8.2. Cautions for flare connection....................................................... 7
9. Refrigerant piping.......................................................................7
9.1. Preventing foreign objects from entering ..................................... 8
9.2. Cautions for handling stop valve.................................................. 8
9.3. How to use the stop valve............................................................ 8
9.4. Cautions for handling the valve cover.......................................... 8
9.5. Cautions for handling service port............................................... 8
9.6. Precautions when connecting field piping
and regarding insulation .............................................................. 9
9.7. Example of connection .............................................................. 10
9.8. Leak test and vacuum drying..................................................... 11
9.9. Additional refrigerant charge...................................................... 11
9.10. Important information regarding the refrigerant used ................ 12
9.11. 3 procedures for adding refrigerant ........................................... 12
10. Electrical wiring work ...............................................................14
10.1. Internal wiring – Parts table ....................................................... 14
10.2. Precautions on electrical wiring work ........................................ 15
10.3. Connection example of total system wiring ............................... 15
10.4. Connecting power wire and transmission wires......................... 15
10.5. Power circuit and cable requirements........................................ 16
11. Before operation.......................................................................17
11.1. Service precautions ................................................................... 17
11.2. Checks before initial start-up ..................................................... 17
11.3. Field setting ............................................................................... 18
11.4. Test operation ............................................................................ 19
11.5. Temperature adjustment operation confirmation ....................... 20
12. Service mode operation ...........................................................21
13. Caution for refrigerant leaks.....................................................21
13.1. Introduction................................................................................ 21
13.2. Maximum concentration level .................................................... 21
13.3. Procedure for checking maximum concentration....................... 21
14. Disposal requirements .............................................................22
1. SAFETY CONSIDERATIONS
The precautions listed here are divided into the following two types.
Both cover very important topics, so be sure to follow them carefully.
Warning
■ Ask your dealer or qualified personnel to carry out installation
work. Do not install the machine by yourself.
Improper installation may result in water leakage, electric shocks
or fire.
■ Perform installation work in accordance with this installation
manual.
Improper installation may lead to water leakage, electric shocks
or fire.
■ When a unit is installed in a small room, it is necessary to take
measures so that the leaked refrigerant amount does not
exceed the limit even if it leaks. As for the measures to prevent
the leak from not exceeding the limit, please consult with your
distributor.
If the leaked amount exceeds the limit, it may cause an oxygen
deficiency accident.
■ Be sure to use only the specified accessories and parts for
installation work.
Failure to use the specified parts may result in water leakage,
electric shocks, fire, or the unit falling.
■ Install the air conditioner on a foundation that can withstand its
weight.
Insufficient strength may result in the fall of equipment and
causing injury.
■ Carry out the specified installation work in consideration of
strong winds, typhoons, or earthquakes.
Improper installation work may result in accidents due to fall of
equipment.
■ Make certain that all electrical work is carried out by qualified
personnel according to the local laws and regulations and this
installation manual, using a separate circuit.
Insufficient capacity of the power supply circuit or improper
electrical construction may lead to electric shocks or fire.
RMXS112E8V1B
RMXS140E8V1B
RMXS160E8V1B
System air conditioner
Installation manual
Super Multi Plus
READ THESE INSTRUCTIONS CAREFULLY BEFORE
INSTALLATION. KEEP THIS MANUAL IN A HANDY
PLACE FOR FUTURE REFERENCE.
IMPROPER INSTALLATION OR ATTACHMENT OF
EQUIPMENT OR ACCESSORIES COULD RESULT IN
ELECTRIC SHOCK, SHORT-CIRCUIT, LEAKS, FIRE OR
OTHER DAMAGE TO THE EQUIPMENT. BE SURE ONLY
TO USE ACCESSORIES MADE BY DAIKIN WHICH ARE
SPECIFICALLY DESIGNED FOR USE WITH THE
EQUIPMENT AND HAVE THEM INSTALLED BY A
PROFESSIONAL.
DAIKIN EQUIPMENT IS DESIGNED FOR COMFORT
APPLICATIONS. FOR USE IN OTHER APPLICATIONS,
PLEASE CONTACT YOUR LOCAL DAIKIN DEALER.
IF UNSURE OF INSTALLATION PROCEDURES OR USE,
ALWAYS CONTACT YOUR DEALER FOR ADVICE AND
INFORMATION.
WARNING
If the warning is not observed, it may cause serious casualties.
CAUTION
If the caution is not observed, it may cause injury or damage to the
equipment.
