4 Preparation
Installation and operation manual
8
SERHQ020~032BAW1 + SEHVX20~64BAW
Split packaged air-cooled water chiller
4P508019-1D – 2019.11
CAUTION
Appliance not accessible to the general public, install it in a
secured area, protected from easy access.
This unit, both indoor and outdoor, is suitable for
installation in a commercial and light industrial
environment.
4.2 Preparing refrigerant piping
4.2.1 Refrigerant piping requirements
NOTICE
The piping and other pressure-containing parts shall be
suitable for refrigerant. Use phosphoric acid deoxidised
seamless copper for refrigerant.
▪ Foreign materials inside pipes (including oils for fabrication) must
be ≤30mg/10m.
▪ Temper grade: use piping with temper grade in function of the
pipe diameter as listed in table below.
Pipe Ø Temper grade of piping material
≤15.9mm O (annealed)
≥19.1mm 1/2H (half hard)
▪ All piping lengths and distances have been taken into
consideration (see About the piping length in the installer
reference guide).
▪ The pipe thickness of the refrigerant piping shall comply with the
applicable legislation. The minimal pipe thickness for R410A
piping must be in accordance with the table below.
Pipe Ø Minimal thickness t
6.4mm/9.5mm/12.7mm 0.80mm
15.9mm 0.99mm
19.1mm/22.2mm 0.80mm
28.6mm 0.99mm
34.9mm 1.21mm
41.3mm 1.43mm
4.2.2 To select the piping size
Determine the proper size using the following tables and reference
figure (only for indication).
G
L
G1
L2
G2
L1
1
2
Indoor unit Outdoor unit
▪ Piping connection sizes
Indoor unit Gas Liquid Outdoor unit Gas Liquid
SEHVX20BAW Ø25.4mm Ø12.7mm 1× SERHQ020BAW1 Ø22.2mm Ø9.52mm
SEHVX32BAW Ø25.4mm Ø12.7mm 1× SERHQ032BAW1 Ø28.6mm Ø12.7mm
SEHVX40BAW Ø25.4mm Ø12.7mm 2× SERHQ020BAW1 Ø22.2mm Ø9.52mm
SEHVX64BAW Ø25.4mm Ø12.7mm 2× SERHQ032BAW1 Ø28.6mm Ø12.7mm
▪ Field piping sizes
Indoor unit G/G1 L/L1 G2 L2
SEHVX20BAW Ø28.6mm Ø9.52mm — —
SEHVX32BAW Ø28.6mm Ø12.7mm — —
SEHVX40BAW Ø28.6mm Ø9.52mm Ø28.6mm Ø9.52mm
SEHVX64BAW Ø28.6mm Ø12.7mm Ø28.6mm Ø12.7mm
If the hydro module connections do not match the diameter of the
specified piping requirements, the piping diameter requirements
must be met using reducers/expanders (field supply) on the hydro
module connections.
If the indoor unit connections do not match the diameter of the
specified piping requirements, the piping diameter requirements
must be met using reducers/expanders (field supply) on the indoor
unit connections.
Other diameters (mm sizes) can also be used if the required pipe
sizes (inch sizes) are not available, taking the following into account:
▪ select the pipe size nearest to the required size,
▪ use the suitable adapters for the change-over from inch to mm
pipes (field supply).
4.2.3 About the piping length
Maximum piping length and height difference
Maximum allowable piping length 30m
Height difference between indoor and outdoor unit <10m
Height difference between outdoor unit 1 and outdoor
unit 2 (if applicable)
0m
4.3 Preparing water piping
4.3.1 To check the water volume and expansion
vessel pre-pressure
The unit has an expansion vessel of 12 litre with a default pre-
pressure of 1bar.
See the installer and user reference guide for more information.
Minimum water volume
Model Minimum total water volume (l)
20 76
32 110
40 152
