16 | Technical data
Installer reference guide
84
RZASG100~140MUV/Y
Sky Air Advance-series
4P743506-1 – 2023.08
1 Refer to the wiring diagram sticker (on the back of the front plate) for how
to use the BS1~BS3 and DS1 switches.
2 When operating, do not short-circuit protective devices S1PH S1PLand
Q1E.
3 Refer to the combination table and the option manual for how to connect
the wiring to X6A, X28A and X77A.
4 Colours: BLK: black, RED: red, BLU: blue, WHT: white, GRN: green, YLW:
yellow.
(4) Legend
English Translation
Legend Legend
Field supply Field supply
Optional Optional
Part n° Part n°
Description Description
A1P Printed circuit board (main)
A2P Printed circuit board (noise filter)
BS1~BS3 (A1P) Push button switch on PCB
C* (A1P) (Y only) Capacitor
DS1 (A1P) Dipswitch
E* (A1P) Terminal (noiseless earth)
F*U Fuse
H*P (A1P) Light-emitting diode (service monitor is green)
K1M, K3M (A1P) (Y only) Magnetic contactor
K1R (A1P) Magnetic relay (Y1S)
K2R (A1P) Magnetic relay (Y2S)
K10R, K13R~K15R (A1P) Magnetic relay
K11M (A1P) (V only) Magnetic contactor
L* (A1P) Terminal (live)
L1R (Y only) Reactor
M1C Compressor motor
M1F Fan motor
N* (A1P) Terminal (neutral)
PFC (A1P) (V only) Power factor correction
PS (A1P) Switching power supply
Q1 Overload protection
Q1DI Earth leakage circuit breaker (30mA)
R1~R8 (A1P) (Y only) Resistor
R1T Thermistor (air)
