9 | Charging refrigerant

Installer reference guide

RZASG100~140MUV/Y

Sky Air Advance-series

4P743506-1 – 2023.08

9 Charging refrigerant

In this chapter

9.1 About charging refrigerant..................................................................................................................................................... 56

9.2 About the refrigerant ............................................................................................................................................................. 58

9.3 Precautions when charging refrigerant ................................................................................................................................. 59

9.4 Definitions: L1~L7, H1, H2 ...................................................................................................................................................... 59

9.5 Charging additional refrigerant .............................................................................................................................................. 60

9.5.1 To determine the additional refrigerant amount.................................................................................................. 60

9.5.2 Charging refrigerant: Setup ................................................................................................................................... 61

9.5.3 To charge additional refrigerant............................................................................................................................ 61

9.6 Completely recharging refrigerant......................................................................................................................................... 62

9.6.1 To determine the complete recharge amount...................................................................................................... 62

9.6.2 To activate/deactivate the vacuum mode field setting ........................................................................................ 62

9.6.3 Charging refrigerant: Setup ................................................................................................................................... 63

9.6.4 To completely recharge refrigerant....................................................................................................................... 63

9.7 To fix the fluorinated greenhouse gases label....................................................................................................................... 63

9.1 About charging refrigerant

The outdoor unit is factory charged with refrigerant, but in some cases the

following might be necessary:

What When

Charging additional refrigerant When the total liquid piping length is

more than specified (see later).

Completely recharging refrigerant Example:

▪ When relocating the system.

▪ After a leak.

Charging additional refrigerant

Before charging additional refrigerant, make sure the outdoor unit's external

refrigerant piping is checked (leak test, vacuum drying).

INFORMATION

Depending on the units and/or the installation conditions, it might be necessary to

connect electrical wiring before you can charge refrigerant.

Typical workflow – Charging additional refrigerant typically consists of the following

stages:

1 Determining if and how much you have to charge additionally.

2 If necessary, charging additional refrigerant.

3 Filling in the fluorinated greenhouse gases label, and fixing it to the inside of

the outdoor unit.

Completely recharging refrigerant

Before completely recharging refrigerant, make sure the following is done:

1 All refrigerant is recovered from the system.

2 The outdoor unit's external refrigerant piping is checked (leak test, vacuum

drying).
