7 | Piping installation

Installer reference guide

RZASG100~140MUV/Y

Sky Air Advance-series

4P743506-1 – 2023.08

7 Piping installation

In this chapter

7.1 Preparing refrigerant piping................................................................................................................................................... 34

7.1.1 Refrigerant piping requirements ........................................................................................................................... 34

7.1.2 Definitions: L1~L7, H1, H2...................................................................................................................................... 35

7.1.3 Refrigerant piping material .................................................................................................................................... 35

7.1.4 Refrigerant piping diameter................................................................................................................................... 35

7.1.5 Refrigerant piping length and height difference ................................................................................................... 36

7.1.6 Refrigerant piping insulation.................................................................................................................................. 37

7.2 Connecting the refrigerant piping.......................................................................................................................................... 37

7.2.1 About connecting the refrigerant piping............................................................................................................... 37

7.2.2 Precautions when connecting the refrigerant piping............................................................................................ 38

7.2.3 Guidelines when connecting the refrigerant piping.............................................................................................. 39

7.2.4 Pipe bending guidelines ......................................................................................................................................... 39

7.2.5 To flare the pipe end.............................................................................................................................................. 39

7.2.6 To braze the pipe end ............................................................................................................................................ 40

7.2.7 Using the stop valve and service port.................................................................................................................... 41

7.2.8 To connect the refrigerant piping to the outdoor unit ......................................................................................... 42

7.3 Checking the refrigerant piping.............................................................................................................................................. 46

7.3.1 About checking the refrigerant piping................................................................................................................... 46

7.3.2 Precautions when checking the refrigerant piping ............................................................................................... 46

7.3.3 Checking refrigerant piping: Setup ........................................................................................................................ 47

7.3.4 To perform a leak test............................................................................................................................................ 47

7.3.5 To perform vacuum drying .................................................................................................................................... 48

7.1 Preparing refrigerant piping

7.1.1 Refrigerant piping requirements

NOTICE

The piping and other pressure-containing parts shall be suitable for refrigerant. Use

phosphoric acid deoxidised seamless copper for refrigerant piping.

INFORMATION

Also read the precautions and requirements in the "2 General safety

precautions"[47].

▪ Foreign materials inside pipes (including oils for fabrication) must be

≤30mg/10m.

When connecting multiple indoor units to the outdoor unit, mind the following:

Refrigerant branch kit One or more refrigerant branch kits are required. See

"5.2.1Possible options for the outdoor unit"[423].

Upward and downward

piping

Perform upward and downward piping only on the

main piping line (L1).

Branch pipes ▪ Install the branch pipes horizontally (with a

maximum inclination of 15°) or vertically.

▪ Make the length of the branch pipes to the indoor

units as short as possible.

▪ Try to keep length of the branch pipes to the indoor

units equal.
