12 Technical data
Installer reference guide
37
RZAG71~140L7V1B
Split system air conditioners
4P418663-1 – 2016.02
RZAG71 RZAG100 RZAG125 RZAG140
Drain Quantity 5
Type Hole
Diameter (OD) Ø26mm
Piping length Minimum 3m
Maximum 55m 85m
Equivalent 75m 100m
Chargeless 30m
Additional refrigerant charge See "To determine the additional refrigerant amount"
Maximum height difference between outdoor
unit and indoor unit
30m
Heat insulation Both liquid and gas pipes
Defrost method Reverse cycle
Defrost control Sensor for outdoor heat exchanger temperature
Capacity control method Inverter-controlled
Safety devices Manual high pressure switch / Automatic high pressure switch / low pressure switch / fan driver
overload protector / fuse
Electrical specifications
RZAG71 RZAG100 RZAG125 RZAG140
Power supply
Name V1
Phase 1~
Frequency 50Hz
Voltage 220-240V
Voltage range Minimum 198V
Maximum 264V
Current
Minimum S
sc
value Equipment complying with EN 61000‑3‑12
(a)
Recommended fuses 20A 32A
Wiring connections
For power supply See "Connecting the electrical wiring"
For connection with indoor
Power supply intake Outdoor unit only
(a) European/International Technical Standard setting the limits for harmonic currents produced by equipment connected to public low-voltage
systems with input current >16A and ≤75A per phase.
