12 Technical data
Installer reference guide
25
RZAG71~140L7V1B
Split system air conditioners
4P418663-1 – 2016.02
12 Technical data
Latest information can be found in the technical engineering data.
12.1 Overview: Technical data
This chapter contains information about:
• Dimensions
• Service space
• Components
• Piping diagram
• Wiring diagram
• Technical specifications
12.2 Dimensions: Outdoor unit
RZAG71 (dimensions in mm)
h
e
e
f
g
e
f
g
a
b
d
c
3D103893
i
52
13
67
53
223
95
55
84
55
19
80
145
53
95
19
89
142
53
95
88
60
28
990
940
32
345
(340〜350)
160 620
160
37
91
30 320 30
37
52
40
32
191
154 179
36
6
19
99
16
16
331
337
71
58
a Gas pipe connection (Ø15.9 flare connection)
b Liquid pipe connection (Ø9.5 flare connection)
c Internal service port (in the unit)
d Earthing terminal M5 (in the switch box)
e Refrigerant piping intake
f Power supply wiring intake (knockout hole Ø34)
g Control wiring intake (knockout hole Ø27)
h Drain hole
i Anchor point (bolt 4× M12)
